Lian Li O11D EVO RGB, Tempered Glass, Black

Anti-dust filter Design - Yes
Audio input Ports & interfaces - Yes
Bottom fans diameters supported Cooling - 120/140 mm
Bottom radiator sizes supported Cooling - 240/280/360 mm
category - Cases & Modding|PC Cases|Mid Towers|Windowed Mid Towers
Category Code - CAS
code - O11DERGBX
Cooling - Bottom fans diameters supported - 120 mm
Cooling - Bottom fans diameters supported - 140
Cooling - Bottom radiator sizes supported - 240 mm
Cooling - Bottom radiator sizes supported - 280
Cooling - Bottom radiator sizes supported - 360
Cooling - Number of bottom fans supported (max) - 3
Cooling - Number of rear fans supported (max) - 1
Cooling - Number of side fans supported (max) - 3
Cooling - Number of top fans supported (max) - 3
Cooling - Rear fans diameters supported - 120 mm
Cooling - Side fans diameters supported - 120 mm
Cooling - Side fans diameters supported - 140 mm
Cooling - Side radiator sizes supported - 240 mm
Cooling - Side radiator sizes supported - 280 mm
Cooling - Side radiator sizes supported - 360 mm
Cooling - Top fans diameters supported - 120
Cooling - Top fans diameters supported - 140 mm
Cooling - Top radiator sizes supported - 240 mm
Cooling - Top radiator sizes supported - 360 mm
Cooling - Top radiator sizes supported - 420 mm
Depth Weight & dimensions - 478 mm
Description - Introducing the all-new O11D EVO RGB, featuring dual ARGB light strips running through the top and bottom of the chassis，creating a stunning look. And the expanded internal space provides greater component compatibility, bringing an exceptional PC-building experience. TWO COLORS/TWO MODES
Derived from the O11D EVO, the O11D EVO RGB can be displayed in two modes with just a few simple steps, allowing for a left or right view. It also comes in two color options: Black and White. ARGB STRIPS ON THE TOP AND BOTTOM
The O11D EVO RGB features a 1.5mm thick L-shaped ARGB strip at both the top and bottom of the chassis that can switch between 14 different lighting effects, adjust brightness and color, and sync with the motherboard. COMPLETELY UNOBSTRUCTED VIEW
The O11D EVO RGB’s front pillar can now be easily removed, providing a seamless view for showcasing hardware without affecting the case’s structure. LARGER SIZE, HIGHER COMPATIBILITY
Compared to the O11D EVO, the O11D EVO RGB is slightly larger, which provides higher component compatibility: it supports a 420mm radiator at the top (requires a separate bracket, 360mm radiator at the side/bottom, and 3x140mm fans at all three sides. MODULAR DESIGN FLEXIBLE CONFIGURATION
Modularity has always been one of the design languages ​​of the O11D EVO series, and the O11D EVO RGB is no exception. ADJUSTABLE MOTHERBOARD INSTALLATION
The O11D EVO RGB features two sets of pilot holes at different heights, allowing the users to adjust the installation position of the motherboard to accommodate different builds. CUSTOMIZED CABLE MANAGEMENT
O11D EVO RGB features an improved cable management design, featuring large VELCRO straps near the PSU chamber, dual-layer cable clips that can hold both the bulky and thinner cables, and 15mm of extended space from the rear of the PSU chamber for more cable management room. ELEVATE YOUR GPU
O11D EVO RGB comes with the new anti-sag bracket GB-003 with easy height adjustment to support heavy GPUs. FRIENDLY STORAGE CAPACITY
O11D EVO RGB offers multiple easily accessible storage mounting locations that support up to 8 × SSDs or 4 × HDDs + 2 × SSDs. OPTIONAL ACCESSORIES
Included 2 silicone covers for low mode configuration to provide a clean look for cable management.Two L-shaped light strips on top and bottom with befitting lighting effectsFront and side tempered glass panels with a removable pilar for a seamless view of components and RGB lighting2 heights adujustable motherboard rear I/O and mounting pointsSupports up to 420mm radiator on top, and 360mm radiator on side and bottomSupports 140mm fans x3 on top, side, and bottomCable management friendly with more space at the second chamberOptional accesories for vertical GPU or upright GPU mounting
Design - Anti-dust filter - Yes
Design - Form factor - Tower
Design - Illumination - Yes
Design - Illumination colour - Multi
Design - Material - Aluminium
Design - Material - Steel
Design - Material - Tempered glass
Design - Maximum CPU cooler height - 16.7 cm
Design - Maximum graphics card length - 45.6 cm
Design - Number of expansion slots - 7
Design - On/off button - Yes
Design - Product colour - Black
Design - Reset button - Yes
Design - Side window - Yes
Design - Supported motherboard form factors - ATX
Design - Supported motherboard form factors - EATX
Design - Supported motherboard form factors - Mini-ITX
Design - Tempered glass panel(s) - Yes
Design - Type - PC
dimensionalWeight - 25429
ean - 4718466014153
Form factor Design - Tower
HDD/SSD combo cage Storage - Yes
Height Weight & dimensions - 471 mm
Illumination colour Design - Multi
Illumination Design - Yes
Material Design - Aluminium/Steel/Tempered glass
Maximum CPU cooler height Design - 167 mm
Maximum graphics card length Design - 455.7 mm
Model - O11DERGBX
Model name - O11 DYNAMIC EVO RGB
name - Lian Li O11D EVO RGB, Tempered Glass - black
Number of bottom fans supported (max) Cooling - 3
Number of expansion slots Design - 7
Number of rear fans supported (max) Cooling - 1
Number of side fans supported (max) Cooling - 3
Number of top fans supported (max) Cooling - 3
On/off button Design - Yes
Ports & interfaces - Audio input - Yes
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB Type-C ports quantity - 1
producerCode - GELI-942
Product colour Design - Black
productName - Lian Li O11D EVO RGB, Tempered Glass - black
productSize - Normal
Rear fans diameters supported Cooling - 120 mm
Reset button Design - Yes
Safety warning - Warnings - Beware of sharp edges during assembly.
Safety warning - Warnings - Keep the product away from water sources to prevent electrical damage.
Side fans diameters supported Cooling - 120/140 mm
Side radiator sizes supported Cooling - 240/280/360 mm
Side window Design - Yes
sizeX - 540
sizeY - 610
sizeZ - 386
SSD form factor Storage - 2.5"
Storage - HDD/SSD combo cage - Yes
Storage - SSD form factor - 2.5"
Storage - Supported HDD sizes - 3.5"
Summary - Lian Li 011 Dynamic EVO RGB O11D EVO RGB. Form factor: Tower, Type: PC, Product colour: Black. Side fans diameters supported: 120,140 mm, Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm. Supported HDD sizes: 3.5", SSD form factor: 2.5". Width: 290 mm, Depth: 478 mm, Height: 471 mm
Supported HDD sizes Storage - 3.5 "
Supported motherboard form factors Design - ATX/EATX/Mini-ITX
Technical details - Warranty period - 1 year(s)
Tempered glass panel(s) Design - Yes
Top fans diameters supported Cooling - 120/140 mm
Top radiator sizes supported Cooling - 240/360/420 mm
Type Design - PC
Unit Box Height - 0.55
Unit Box Length - 0.61
Unit Box Width - 0.39
Unit Calculated Volume - 0.1308 cubm
Unit Calculated Weight - 17.4 kg
Units per Shipping Box - 1
USB 2.0 ports quantity Ports & interfaces - 2
USB 3.0 Ports & interfaces - 2
USB Type-C ports quantity Ports & interfaces - 1
Vendor Homepage - https://lian-li.com/product/o11d-evo-rgb/
Warranty - 24 months
warrantyLength - 24
Warranty period Technical details - 1 year(s)
warrantyType - G
weight - 17800
Weight & dimensions - Depth - 478 mm
Weight & dimensions - Height - 471 mm
Weight & dimensions - Width - 290 mm
Width Weight & dimensions - 290 mm
