Asus Radeon RX 9060 XT, 16GB GDDR6, Dual

Brand - ASUS
BrandPartCode - 90YV0LG2-M0NA00
Card's length - 200 to 240 mm
Category - Graphics Cards
Category Code - VGP
Chipset - AMD Radeon RX 9060 XT
Cooling system - Dual Slot Fansink
CUDA Cores - 2048
Description - ASUS Dual Radeon™ RX 9060 XT 16GB GDDR6 Dual Radeon™ RX 9060 XT Dual Fans, Perfect Fit ASUS Dual Radeon™ RX 9060 XT combines powerful thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for optimizing airflow to the heatsink. Designed in a compact 2.5-slot form factor, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.
Design - Cooling technology - ASUS Axial-tech
Design - Cooling type - Active
Design - Number of fans - 2 fan(s)
Design - Number of slots - 2.5
Design - Product colour - Black
Design - SFF ready - Yes
Dimensions - 202 x 120 x 49mm
DisplayPort Input/Output connectors - 2
GPU boost clock - 3250 MHz
Graphic card features - Gaming/HDCP
Graphics connector - PCIE 5.0 16x
Graphics memory size - 16 GB
Graphics memory type - GDDR6
GTIN - 4711636196765
HDMI Input/Output connectors - 1
Included Accessories - 1 x Thank you card
1 x Speedsetup Manual
LongDesc - Dual Radeon™ RX 9060 XTDual Fans, Perfect FitASUS Dual Radeon™ RX 9060 XT combines powerful thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for optimizing airflow to the heatsink. Designed in a compact 2.5-slot form factor, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.Cooling2.5-slot DesignA carefully designed shroud, heatsink, and heatpipe layout enables the two Axial-tech fans to leverage chassis side-panel ventilation, delivering thermal performance that beyond the compact size.Axial-tech UpgradesTwo tried-and-true Axial-tech fans feature a smaller hub facilitates longer blades and a barrier ring to increase downward air pressure.0dB TechnologyTo eliminate unnecessary noise, the stop mode automatically halts all fans when the GPU temperature drops below 55°C and power consumption is low.Dual Ball Fan BearingsFan bearings come in different types, each with its own advantages. Dual ball bearings provide superior durability and can last up to twice as long as sleeve-bearing designs.Vented BackplateA vented backplate significantly enhances heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling.Unmatched ReliabilityASUS GPU GuardASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks.Protective BackplateThe PCB is reinforced by a backplate that adds structural rigidity, helping to prevent flex and to protect components and trace pathways from damage.Stainless Steel BracketThe mounting bracket of the Dual has been beefed up with 304 Stainless Steel that’s harder and more resistant to corrosion.EngineeringDual BIOSDo you prioritize lower core temperatures or quieter operation? Performance mode increases fan speed to keep the card running cool all the time. Quiet mode maintains the same power target and performance settings, but applies a less aggressive fan curve for quieter operation at medium temperatures. Want more control? Customize your experience with GPU Tweak III software for fine-tuned fan profiles and performance adjustments.Auto−Extreme TechnologyAuto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing completing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting and minimizes in less environmental impact. The result is lower power consumption during manufacturing and a more reliable, high-quality product.lower manufacturing power consumption, and a more reliable product overall.
LongProductName - 16 GB, GDDR6, 128-bit, 3250 MHz boost clock, PCI Express 5.0, 2x DisplayPort, 1x HDMI, 1x 8-pin, 2.5 slot
LongSummaryDescription - ASUS Dual -RX9060XT-16G. Graphics processor family: AMD, Graphics processor: Radeon RX 9060 XT. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6, Memory bus: 128 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 5.0. Cooling type: Active, Number of fans: 2 fan(s)
Max resolution - 7680x4320
Memory - Data transfer rate - 20 Gbit/s
Memory - Discrete graphics card memory - 16 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 128 bit
Memory bus - 128 bit
Memory CLK - 20 Gbps
Model - DUAL-RX9060XT-16G
Packaging content - Manual - Yes
Packaging data - Package type - Box
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 2.1a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1b
Ports & interfaces - Interface type - PCI Express 5.0
Power - Minimum system power supply - 550 W
Power - Supplementary power connectors - 1x 8-pin
Power connectors - 8 pin
Processor - CUDA - No
Processor - Graphics processor - Radeon RX 9060 XT
Processor - Graphics processor family - AMD
Processor - Maximum displays per videocard - 3
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor boost clock speed - 3230 MHz
Processor - Processor boost clock speed (Gaming mode) - 2640 MHz
Processor - Processor boost clock speed (OC mode) - 3250 MHz
Processor - Stream processors - 2048
ProductName - DUAL-RX9060XT-16G
Product Net Weight - 0.5 kg
ShortSummaryDescription - ASUS Dual -RX9060XT-16G, Radeon RX 9060 XT, 16 GB, GDDR6, 128 bit, 7680 x 4320 pixels, PCI Express 5.0
System requirements - Windows operating systems supported - Windows 10 x64, Windows 11 x64
Title - ASUS Dual -RX9060XT-16G AMD Radeon RX 9060 XT 16 GB GDDR6
Unit Box Height - 0.07
Unit Box Length - 0.37
Unit Box Width - 0.22
Unit Calculated Volume - 0.006868 cubm
Unit Calculated Weight - 1.2 kg
Units per Pallet - 0
Units per Shipping Box - 8
URL - https://www.asus.com/motherboards-components/graphics-cards/dual/dual-rx9060xt-16g/
Vendor Homepage - www.asus.com/motherboards-components/graphics-cards/dual/dual-rx9060xt-16g/
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 49 mm
Weight & dimensions - Height - 120 mm
Weight & dimensions - Length - 202 mm
