ARTIKEL1 - XS3800-28 MULTIGIG SWITCH
ARTIKEL2 - 28 PORT LAYER2+ MANAGED
Brand - Zyxel
BrandPartCode - XS3800-28-ZZ0101F
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Colour of product - Black
Data transmission - Forwarding rate - 416 Mpps
Data transmission - MAC address table - 32000 entries
Data transmission - Packet buffer memory - 4 MB
Data transmission - Switching capacity - 560 Gbit/s
Description - ZYXEL XS3800-28, 28-PORT 10GBE L2+ MANAGED SWITCH NEBULA FLEX PRO (DUAL AC,1 YEAR NCC PRO PACK LICENSE BUNDLED)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Reset button - Yes
Dimensions W x D x H, mm - 441 x 360 x 44
EAN - 4718937600960
EANCode - 4718937600960
Ethernet LAN (RJ-45) ports quantity - 4
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 4718937600960
Height - 523.000000
HERSTELLER - ZYXEL
HSTNUMMER - XS3800-28-ZZ0101F
Input voltage, V - 100-240
Length - 588.000000
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Flexible port designXS3800-28 offers a maximum of 24 10G fiber ports or 12 10G copper ports that are for most flexible adoption to your networks.Essentials of a core switchXS3800-28 is suitable for network aggregation such as SMB or campus networks that require low latency and high-density 10G backbone architectures with basic routing capability.Restore ButtonThe "Restore" button saves the last workable configuration as the custom default, which allows you to fall back instantly in case of network misconfigurations.Dual PowerTwo PSUs support active-standby power redundancy that triggers backup power supply if the main unit fails.Designed for the long haulQuality hardware design is how Zyxel differentiate ourselves from others. We ensure stability and longevity for XS3800-28 for your networks.
LongProductName - 4 x RJ-45, 8 x Multi-Gigabit combo RJ-45 / SFP+, 16 x SFP+, 560 Gbps, 416 Mpps, 64 MB/8 GB Flash/RAM, 100 - 240 V AC, 50/60 Hz, 441 x 360 x 44 mm
LongSummaryDescription - Zyxel XS3800-28. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 4. MAC address table: 32000 entries, Switching capacity: 560 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE.... Power connector: AC-in jack. Rack mounting
MAC address table, entries - 32 000
Management features - ARP inspection - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - MIB support - Y
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+
Management features - Switch type - Managed
Management features - Traffic classification - Yes
Management features - Traffic shaping - Yes
Management features - Web-based management - Yes
Manufacturer - Zyxel
ManufacturerPartNumber - XS3800-28-ZZ0101F
MPN - XS3800-28-ZZ0101F
Multicast features - Multicast support - Yes
Name - 12+16P Zyxel XS3800-28 M RM
Network - 10G support - Yes
Network - Auto-negotiation - Yes
Network - Broadcast storm control - Yes
Network - Copper ethernet cabling technology - 10GBASE-T, 100BASE-T, 1000BASE-T
Network - Flow control support - Yes
Network - IP routing - Yes
Network - Networking standards - IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
Network - Policy-based routing - Yes
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Operating temperature range (T-T), °C - 0-50
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Optical fiber - Fiber ethernet cabling technology - 1000BASE-X
Packaging content - Cables included - AC
Packaging content - Rack mount kit - Yes
Packet transfer speed - 416
Performance - Flash memory - 64 MB
Performance - Internal memory - 8000 MB
Performance - Mean time between failures (MTBF) - 656274.78 h
PeriodofWarranty -
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 10G Ethernet (100/1000/10000)
Ports & interfaces - Combo SFP ports quantity - 8
Ports & interfaces - Fiber optic connector - SFP+
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP+ module slots quantity - 16
Ports quantity - 28
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Number of power supply units - 2
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power consumption, W - 86.97
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Support - No
ProductName - XS3800-28
RAM memory - 8 GB
Security - Access Control List (ACL) - Yes
Security - Authentication - MAC-based authentication
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP client, DHCP relay, DHCP server
Security - IGMP proxy - Yes
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - MAC address filtering - Yes
Security - Password protection - Yes
Security - SSH/SSL support - Yes
ShortSummaryDescription - Zyxel XS3800-28, Managed, L2+, 10G Ethernet (100/1000/10000), Rack mounting
Stck_Kart - 1
Stck_Pal - 6
Storno - Y
Switching capacity, Gbit/s - 560
Switch type - Managed
Title - Zyxel XS3800-28 Managed L2+ 10G Ethernet (100/1000/10000) Black
URL - https://www.zyxel.com/products_services/28-port-10GbE-L2--Managed-Switch-XS3800-28/introduction
WarrantyInfo -
Weight - 7.100000
Weight & dimensions - Depth - 340 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 4.81 kg
Weight & dimensions - Width - 441 mm
Weight, g - 4810
Width - 132.000000
