Intellinet 560993, 16x1GE PoE

Brand - Intellinet
BrandPartCode - 560993
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Certificates - Certification - FCC Class B, VCCI Class A, CE, RoHS
Dane techniczne: Akcesoria - uchwyty do montażu w szafie 19"
Dane techniczne: Bufor pamięci - 256 KB
Dane techniczne: Grupa produktowa - Przełączniki Intellinet
Dane techniczne: Gwarancja - 3 lata w serwisie zewnętrznym
Dane techniczne: Głębokość - 208 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 16 szt.
Dane techniczne: Porty PoE - 16 szt.
Dane techniczne: Producent - Intellinet
Dane techniczne: Przeznaczenie - do szaf RACK 19"
Dane techniczne: Prędkość magistrali wew. - 32 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 8192
Dane techniczne: Szerokość - 442 mm
Dane techniczne: Szybkość przekierowań pakietów - 1488000 mpps
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Waga - 3.8 kg
Dane techniczne: Wysokość - 44 mm
Data transmission - Forwarding rate - 1.488 Mpps
Data transmission - MAC address table - 8192 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 32 Gbit/s
Design - Form factor - 1U
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
dimensionalWeight - 2997
Eans - 766623560993
GTIN - 766623560993
GTIN - 0766623560993
GTIN - 0809393891703
GTIN - 809393891703
GTIN - 7666235609932
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Save installation time and money with PoE. The Intellinet Network Solutions 16-Port Gigabit Ethernet Rackmount PoE+ Switch (560993) is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with 16 Gigabit Ethernet ports, this switch can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 1,000 Mbps. Power over Ethernet 802.3at The Intellinet Network Solutions 16-Port Gigabit Ethernet PoE+ Switch supports the IEEE 802.3at protocol and is designed to inject up to 30 watts of power per port*. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, thus eliminating the time and expense of electrical rewiring and minimising the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short-circuit, overload and high-voltage protection function, your equipment is well-protected. For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest the use of an Intellinet Network Solutions PoE/PoE+ Splitter. Extreme Throughput With a backplane speed of 32 Gbps, there is plenty of performance available for your computers, servers and other networking devices. * Total PoE budget for this switch is 220 watts.
LongProductName - 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount
LongSummaryDescription - Intellinet 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8192 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Management features - Switch layer - L2
Management features - Switch type - Unmanaged
Name - Intellinet 560993 Switch 16p Gigabit PoE
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-TX, 1000BASE-T
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Packaging content - Cables included - AC
Packaging content - Manual - Yes
Packaging content - Rack mount kit - Yes
Performance - Buffer size - 256 KB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 16
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 260 W
Power - Power protection features - Overload
Power - Power protection features - Over voltage
Power - Power protection features - Over voltage, Overload, Short circuit
Power - Power protection features - Short circuit
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Producent: Nazwa producenta / importera - IntellinetIC INTRACOM Vertriebs GmbHLöhbacher Str 758553 HalverNiemcyEmail: info@ic-intracom.com
Producer - Intellinet
producerCode - 560993
ProducerCode - 560993
ProductName - 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount
productName - Intellinet 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount
productSize - Normal
Safety warning - Warnings - Do not open the case or try to repair it yourself.
Safety warning - Warnings - Ensure the unit is adequately ventilated during operation.
Safety warning - Warnings - The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
ShortDescription - Przełącznik Gigabit Ethernet 16portów POE
ShortSummaryDescription - Intellinet 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
sizeX - 90
sizeY - 300
sizeZ - 555
Title - Intellinet 16-Port Gigabit Ethernet PoE+ Switch, 16 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Rackmount
URL - https://intellinetnetwork.eu/catalogsearch/result/?q=560993
WarrantyInfo - 3 Years
warrantyLength - 36
warrantyType - G
weight - 4000
Weight & dimensions - Depth - 208 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 3.8 kg
Weight & dimensions - Width - 442 mm
