D-Link GO-SW-5G 5x1000Mbit

Number of 10Gb ports - None
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 5
Stck_Pal - 60
Data transmission - Switching capacity - 10 Gbit/s
Data transmission - MAC address table - 2000 entries
Data transmission - Packet forwarding rate (1 Gbps) - 1488000 pps
Data transmission - Packet forwarding rate (10 Mbps) - 14880 pps
Data transmission - Packet forwarding rate (100 Mbps) - 148800 pps
Data transmission - Packet buffer memory - 0.128 MB
Data transmission - Jumbo frames - 9216
Data transmission - Jumbo frames support - Yes
Data transmission - Store-and-forward - Yes
ARTIKEL1 - GO 5-PORT GIGABIT EASY
ARTIKEL2 - DESKTOP SWITCH
Brand - D-Link
BrandPartCode - GO-SW-5G/E
Number of COMBO ports - None
Design - LED indicators - Yes
Design - Rack mounting - No
Design - Product colour - White
Design > Form factor - Desktop
EANCode - 0790069365676
EAN_code - 0790069365676
Eans - 0790069365676
Forwarding rate - 1488 Mpps
Forwarding mode - Store-and-forward
Power consumption - 1.67 W
Category_1 - Network and Servers
EAN - 790069365676
Fan - No
Warranty - 24
guarantee - 24
Warranty - 24 month(s)
WarrantyInfo -
guarantee_type - external
GTIN - 790069365676
GTIN - 0790069365676
GTIN - 7900693656764
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
HSTNUMMER - GO-SW-5G/E
Management features - Switch type - Unmanaged
Management features > Switch type - Unmanaged
Support for Jumbo frames - Yes
Jumbo frame size - 8 KB
Weight - 0,21
Gewicht - 0.21
Weight - 105 g
Weight & dimensions - Weight - 75 g
Weight & dimensions - Width - 94 mm
Weight & dimensions - Depth - 75 mm
Weight & dimensions - Height - 22.4 mm
Category - Root/Electronics/Networks and communication/Switchers
Category - Network Switches
Category_2 - Network - Switches and Hubs
ean - 790069365676
Mean time between failures (MTBF) - 815700 h
Description - 5 miedzianych portów gigabitowych
Dzięki zastosowaniu do transmisji skrętek miedzianych kategorii 5 lub wyższej tych pięć portów umożliwia szybkie uzyskanie w serwerach połączeń gigabitowych bez potrzeby instalowania nowych, kosztownych kabli światłowodowych. Porty gigabitowe zapewniają serwerom wydzielone pasmo 2000 Mb/s w trybie pełno dupleksowym. Dzięki temu stacje robocze mają jednoczesny dostęp do danych na serwerze bez „wąskich gardeł".
Kontrola przepływu IEEE 802.3x
Funkcja ta umożliwia regulowanie przepływu danych pomiędzy przełącznikiem i serwerem w celu zagwarantowania niezawodnej transmisji. Przy 2000 Mb/s w trybie pełno dupleksowym przełącznik zapewnia szybkie łącza danych z serwerami z minimalnym poziomem utraty danych w czasie transmisji.
Automatyczne rozpoznawanie kabla krosowego (MDI/MDIX)
Wszystkie porty obsługują automatyczne rozpoznawanie kabla krosowego (MDI/MDIX). Eliminuje to konieczność stosowania kabli krosowych lub portów do łączy nadrzędnych (uplink). Każdy port można po prostu połączyć z serwerem, koncentratorem lub przełącznikiem za pomocą zwykłego kabla bezpośredniego typu skrętka.
Instalacja typu „podłącz i pracuj"
Przełącznik integruje się bez problemów z dotychczas używanymi urządzeniami sieciowymi, bez względu na to, czy jest to sieć Ethernet, Fast Ethernet, czy Gigabit Ethernet, dzięki czemu nie ma potrzeby wymiany sprzętu lub oprogramowania. Sieć można uruchomić w kilka minut — wystarczy podłączyć kable do przełącznika. Przełącznik integruje się bez problemów z dotychczas używanymi urządzeniami sieciowymi, bez względu na to, czy jest to sieć Ethernet, Fast Ethernet, czy Gigabit Ethernet, dzięki czemu nie ma potrzeby wymiany sprzętu lub oprogramowania. Sieć można uruchomić w kilka minut — wystarczy podłączyć kable do przełącznika.
vendpn - GO-SW-5G/E
Accessories included -
Code - GO-SW-5G/E
Hoehe - 0.09
L2 features -
L3 features -
Laenge - 0.12
Breite - 0.11
Link - https://us.dlink.com/en/products/go-sw-5g-5-port-gigabit-unmanaged-desktop-switch
Logistics data - Harmonized System (HS) code - 85176990
ShortDescription -
ShortSummaryDescription - D-Link 5-Port Gigabit Easy Desktop Switch, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex
MAC address table size - 2000
Other functions -
Other features -
Other features > Power supply type - External
Memory buffer - 128 KB
Designation - CE+WEEE
dimension height - 120 mm
dimension width - 85 mm
dimension depth - 100 mm
Dimensions - 97 x 79 x 28 mm
dimension weight - 220 g
name - 5-port switch 5xGbE
Name - D-Link GO-SW-5G
Name - D-Link GO-SW-5G 1000/UNM/ 5
Name - D-Link | Switch | GO-SW-5G/E | Unmanaged | Desktop | Gigabit Ethernet (copper) ports quantity 5 | Power supply type External
Package features > Gross height master carton - 225 mm
Package features > Gross width (mm) - 102.11 mm
Package features > Gross width master carton - 210 mm
Package features > Gross depth master carton - 310 mm
Package features > Gross height (mm) - 84.07 mm
Package features > Gross depth (mm) - 118.11 mm
Package features > Volume (m3) - 0.00 m³
Package features > Net weight master carton - 3 kg
Package features > Paper/Pasteboard - 90 g
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 852 pc(s)
Package features > Plastic (No PET) - 10 g
Package features > Tare weight (kg) - 0.1 kg
Package features > Tare weight master carton - 0.249 kg
Packaging content - Manual - Yes
Package features > PET - 4 g
Package features > Embeeded battery - No
Package features > WEEE tax - Yes
Package features > WEE classification - CL109:6:2017-04-01
Title - D-Link 5-Port Gigabit Easy Desktop Switch
LongDesc - The dlinkgo 5-Port Gigabit Easy Desktop Switch (GO-SW-5G) offers an economical way for SOHO and small to medium businesses benefit from the increased bandwidth of Gigabit Ethernet. It provides Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity.The dlinkgo GO-SW-5G 5-Port Gigabit Easy Desktop Switch is part of D-Link’s new series of SOHO devices that make use of D-Link’s Green Technology, providing energy savings, reduced heat, and a longer product life without sacrificing performance or functionality. It provides five Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity. An energy-efficient power adapter (Energy Star Level VI qualified), minimised use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly.Fast and Reliable Networking The D-Link GO-SW-5G 5-Port Gigabit Easy Desktop Switch creates a blazing fast network for your office, as its Gigabit Ethernet ports provide high-speed wired connections for up to five PCs or other devices. The GO-SW-5G also features QoS, which prioritises network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. Finally, plug and play support makes setup a breeze.Conserve Energy The 5-Port Gigabit Easy Desktop Switch helps you conserve energy automatically through several methods. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which cuts down on power consumption during periods of low data activity and will proceed to put the unused port into sleep mode, saving a substantial amount of power. It also adjusts the amount of power supplied to a port according to the length of the connected Ethernet cable.Environmentally-friendlyThe 5-Port Gigabit Easy Desktop Switch was designed with the environment in mind and is compliant with Energy Star Level VI, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimise the use of hazardous materials and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.
LongSummaryDescription - D-Link 5-Port Gigabit Easy Desktop Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. DC input voltage: 5 V
LongProductName - 5 x 10/100/1000BASE-T Gigabit LAN, MAC 4K, Jumbo frame, 94x75x22.45 mm
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 5
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Certificates - Certification - CE class B, FCC class B, ICES-003 class B, VCCI class B, BSMI, LVD, RCM, Anatel, KCC
Number of SFP+ ports - None
Number of SFP ports - None
Stck_Kart - 20
Application - Home and small office
QoS -
Dane techniczne: Gwarancja - 2 lata w serwisie zewnętrznym
Dane techniczne: Waga - 0.105 kg
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Wysokość - 79 mm
Dane techniczne: Szerokość - 97 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 5 szt.
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Rozmiar tablicy adresów MAC - 2000
Dane techniczne: Głębokość - 28 mm
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Obsługiwane protokoły - IEEE 802.3i
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ab
Dane techniczne: Obsługiwane protokoły - IEEE 802.3az
Dane techniczne: Grupa produktowa - Przełączniki D-link
Dane techniczne: Producent - D-link
Dane techniczne: Typ - niezarządzalny
Technical details > Gross weight - 0.204 kg
Technical details > Net weight - 0.10 kg
Technical details > Producer - D-Link
Technical_details - Connect All of Your Devices with Gigabit Speed
Expand your wired home network with the D-Link® 5-Port Unmanaged Gigabit Desktop Switch (GO-SW-5G). By connecting the GO-SW-5G to your router, you can add up to four more computers to your home network with Fast Ethernet connectivity. Add devices like your gaming console, printer, print server, Network-Attached Storage (NAS) or network camera with a simple Ethernet cable. Compact Design
This Desktop Switch fits virtually anywhere because of its compact size. Its power connector and ports are conveniently located in the rear to avoid messy cables on the desk. Effortless High Speed Networking
Featuress easy access auto sensing Gigabit front Ethernet ports with a LED indicator for each port to quickly distinguish link status and activity. The GO-SW-5G switch also supports Auto MDI/MDIX Crossover allowing each port to be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables to get you the maximum speed possible for each device connected to your network. Plug and Play Installation
TheD-Link® 5-Port Gigabit Desktop Switch is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free. But we know that setting up your switch is only the beginning; you can also easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multi-player gaming environment. D-Link Green Technology
The GO-SW-5G 5-Port Unmanaged Gigabit Switch is part of D-Link’s new series of SOHO devices that make use of D-Link’s Green Technology, providing energy savings, reduced heat, and a longer product life without sacrificing performance or functionality. An energy-efficient power adapter (EnergyStar Level V qualified), minimized use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly. Transfer Rate LAN 10/100/1000 MBit/s LEDs Activity, 5x Lan, Power Ports RJ-45 LAN 5 Features QoS Product dimensions 91 x 22 x 73 mm
Supported protocols and standards - • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twistedpair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
Power supply -
ProductName - 5-Port Gigabit Easy Desktop Switch
producer - D-Link
Producer - D-link
HERSTELLER - D-LINK
Manufacturer - D-Link
Producent: Nazwa producenta / importera - D-link
D-Link (Polska) Sp. z o.o.
ul. Mysikrólika 11a
02-809 Warszawa
ProducerCode - GO-SW-5G
Manufacturer_code - GO-SW-5G/E
Producer product name - GO-SW-5G/E
Producer product family - Switch
Security -
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Storno - Y
Switch class - Unmanaged
URL - https://eu.dlink.com/uk/en/products/go-sw-5g-5-port-gigabit-desktop-switch
VLAN -
Power - DC input voltage - 5 V
Power - Input current - 1 A
Power - Power source - DC
Power - Power consumption (max) - 2.87 W
Network architecture - GigabitEthernet
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Chassis type - Desktop
