D-Link DGS‑108 8-Port Gigabit Unmanaged Desktop Switch

Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Stck_Pal - 20
Data transmission - Switching capacity - 16 Gbit/s
Data transmission - MAC address table - 8000 entries
Data transmission - Maximum data transfer rate - 1 Gbit/s
Data transmission - Packet buffer memory - 0.128 MB
Data transmission - Jumbo frames support - Yes
Data transmission - Store-and-forward - Yes
Data transmission - Supported data transfer rates - 10/100/1000 Mbps
ARTIKEL1 - 8-PORT LAYER2 GIGABIT SWITCH
ARTIKEL2 - IN
Brand - D-Link
BrandPartCode - DGS-108/E
Number of COMBO ports - None
Design - Housing material - Metal
Design - LED indicators - Link, Power
Design - Rack mounting - No
Design - Product colour - Black
Design > Form factor - Desktop
EANCode - 0790069368240
EAN_code - 0790069368240
Eans - 790069368240
Power consumption - 4.5 W
Category_1 - Network and Servers
EAN - 0790069368240
Fan - No
guarantee - -1
Warranty - 60
WarrantyInfo -
guarantee_type - external
GTIN - 790069368240
GTIN - 0790069368240
GRUPPE1 - Network
GRUPPE2 - Switches Managed
Management features - Quality of Service (QoS) support - Yes
HSTNUMMER - DGS-108/E
Management features > Switch type - Unmanaged
Support for Jumbo frames - Yes
Performance - Mean time between failures (MTBF) - 2053751 h
Weight - 0,69
Weight - 440 g
Weight & dimensions - Weight - 440 g
Category - Root/Electronics/Networks and communication/Switchers
Category - Network Switches
Category_2 - Network - Switches and Hubs
ean - 790069368240
Mean time between failures (MTBF) - 2053751 h
Gross Weight Kg - 0,48
vendpn - DGS-108/E
Code - DGS-108/E
Hoehe - 0.07
Laenge - 0.26
Breite - 0.21
Link - https://eu.dlink.com/uk/en/products/dgs-108-8-port-gigabit-ethernet-switch
Logistics data - Harmonized System (HS) code - 85176990
Throughput - 16 Gb/s
ShortDescription -
Short description - D-Link Switch DGS-108/E 8xGBit Unmanaged
ShortSummaryDescription - D-Link DGS-108, Full duplex
Switch layer - L2
MAC address table size - 8000
Other features - Connectivity technology - Wired
Other features - Data transfer rate - 2000 Mbit/s
Other features - Dimensions (WxDxH) - 162 x 102 x 28 mm
Memory buffer - 128 KB
Designation - CE+WEEE
dimension height - 255 mm
dimension width - 210 mm
dimension depth - 73 mm
Dimensions - 162 x 102 x 28 mm
dimension weight - 734 g
Name - D-Link DGS-108 1000/UNM/ 8
Name - D-Link DGS-108/E
Name - D-Link | Switch | DGS-108/E | Unmanaged | Desktop | Gigabit Ethernet (copper) ports quantity 8 | 60 month(s)
name - DGS-108 switch L2 8x1GB Desktop
Packaging data - Included power plug types - EU
Packaging data - Package weight - 654 g
Packaging data - Package height - 68 mm
Packaging data - Package width - 208 mm
Packaging data - Package depth - 250 mm
Package features > Gross height master carton - 453 mm
Package features > Gross width (mm) - 253 mm
Package features > Gross width master carton - 365 mm
Package features > Gross depth master carton - 275 mm
Package features > Gross height (mm) - 210 mm
Package features > Gross depth (mm) - 69 mm
Package features > Volume (m3) - 0.00366597 m³
Package features > Net weight master carton - 7.12 kg
Package features > Paper/Pasteboard - 690.00 g
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 380 pc(s)
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.411 kg
Package features > Tare weight master carton - 0.773 kg
Package features > PET - 4 g
Package features > Embeeded battery - No
Package features > WEEE tax - Yes
Package features > WEE classification - CL109:6:2017-04-01
Title - D-Link DGS-108 Black
LongDesc - - Plug and Play operation- 8 Gigabit Ethernet ports- Non-blocking architecture: simultaneous full speed on all ports- Fanless, silent operation to fit in any environment- Quality of Service (QoS) queues for traffic prioritisation- Solidly built with metal housing- Cable diagnostics function to detect faulty network cables- D-Link Green™ technology, saves energy and increases the product’s lifespanD-Link’s DGS-108 Gigabit Ethernet switch provides a cost-effective way for SOHO and SMB to create a small network and connect computers, wireless Access Points, IP cameras, network printers and other Ethernet devices quickly and easily without complicated configurations. This switch comes with 8 Gigabit Ethernet ports with an auto-sensing function to detect the maximum speed of the connected devices, allowing you to run your network with the best possible performance. Its fanless design makes the DGS-108 completely silent, ideal for offices, libraries or meeting rooms.Robust designThe DGS-108 is designed with durability and performance in mind. The sturdy metal housing will protect the switch against accidental harm, while helping to dissipate heat and to reduce stress on internal components. The visible LEDs allow for an easy reading of each port status and speed, helping to troubleshoot connectivity problems. For a convenient placement, the DGS-108 comes with a wall mounting kit and a slot for a Kensington security lock to protect it from theft.QoS (Quality of Service)Despite being an unmanaged, Plug and Play switch, the DGS-108 is able to classify network traffic by assessing the 802.1p field in the Ethernet frames, and forward them out of its ports depending on their priority. This allows for a smooth integration of video, voice and data traffic without delays or loss of quality.Cable diagnostics functionThe cable diagnostics function enables users to quickly troubleshoot faulty network cables that may lead to transmission errors. At startup, the switch performs a micro-test to assess the quality of the cables connected to its ports. If a fault is detected, the ambar LED will lit up. If the cables pass the test, the green LED will be illuminated, indicating that the network is error-free. This feature can save valuable time when trying to single out a faulty cable that causes problems in the whole network.Power-saving technologyThe DGS-108 is part of D-Link Green™, D-Link’s eco-friendly technology, providing energy savings, reduced power consumption, and a longer product lifespan without sacrificing operational performance or functionality. This switch implements the 802.3az Energy Efficient Ethernet (EEE) standard, which can save a substantial amount of energy by detecting the port status, putting them in low-power, stand-by mode when no network traffic is detected. Additionally, the Green Ethernet™ technology in the DGS-108 can detect the length of the network cables connected to its ports and provide only the right amount of energy required. This helps businesses to save money by reducing their electricity bills with no compromise on performance.
LongSummaryDescription - D-Link DGS-108. Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack
LongProductName - 8-Port 10/100/1000 Gigabit, Auto MDI/MDIX, Full/half-duplex, Jumbo Frames, 16 Gbps, QoS
Number of PoE ports (PoE & PoE+) - None
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 8
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Certificates - Certification - FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB, RoHS
Number of SFP ports - None
Stck_Kart - 20
Application - Home and small office
Technical details - Pallet gross width - 120 cm
Technical details - Pallet gross length - 110 cm
Technical details - Pallet height (air) - 196.7 cm
Dane techniczne: Gwarancja - 5 lat w serwisie zewnętrznym
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Liczba portów LAN 10/100/1000 - 8 szt.
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Warstwa przełączania - 2
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Grupa produktowa - Przełączniki D-link
Dane techniczne: Producent - D-link
Dane techniczne: Typ - niezarządzalny
Technical details > Gross weight - 0.712 kg
Technical details > Warranty - 60 month(s)
Technical details > Net weight - 0.301 kg
Technical details > Producer - D-Link
Technical details - Pallet gross weight (sea) - 398.9 kg
Technical details - Pallet gross weight (air) - 398.9 kg
Technical details - Pallet height (sea) - 196.7 cm
Technical details - Master (outer) cases per pallet (sea) - 48 pc(s)
Technical details - Master (outer) cases per pallet (air) - 48 pc(s)
Technical details - Products per pallet (sea) - 480 pc(s)
Technical details - Products per pallet (air) - 480 pc(s)
Technical details - Products per shipping (inner) case - 10 pc(s)
Technical details - Shipping (inner) case gross weight - 7.79 kg
Technical details - Shipping (inner) case width - 26 cm
Technical details - Shipping (inner) case net weight - 7.1 kg
Technical details - Shipping (inner) case height - 44.3 cm
Technical details - Shipping (inner) case length - 37 cm
Technical_details - Effortless Gigabit Networking
With data transfer speeds of up to 2000 Mbps on Gigabit Ethernet, the D-Link DGS-108 8 Port Gigabit Switch is ideal for transferring files quickly. Featuring easy access front Ethernet ports with two color LED indicators per port to quickly distinguish link status. The switch supports IEEE 802.1p QoS, which organizes and prioritizes time-sensitive and important data for efficient delivery, allowing for smooth streaming media, VoIP calling, and online gaming. Additionally the switch incorporates a Kensington Security Slot on the rear panel allowing users to securely fasten the unit to a table or desk. Think Green
The DGS-108 is a plug-and-play networking switch that offers D-Link’s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, at which time the switch will automatically power down the idle port, saving a substantial amount of power. In addition, the switch can also save energy by detecting the length of cable connected to a port and only using as much power as is necessary. Working together these Featuress drastically reduce power consumption and heat dissipation, resulting in extended life and substantial cost savings. Environmentally Friendly
The DGS-108 Gigabit switch was designed with the environment in mind. It is compliant with Energy Star Level V, CEC, and MEPS regulations which require the use of energy efficient power adapters. Built to comply with RoHS standards to minimize use of hazardous materials and is packaged with an EnergyStar Level V qualified power adapter all in a recyclable packaging making this product truly environmental friendly. Transfer Rate LAN 10/100/1000 MBit/s LEDs Activity, 8x Lan, Speed, Power Ports RJ-45 LAN 8 Features QoS, Layer 2 Product dimensions 162 x 28 x 102 mm RoHS Compliant Yes
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.1pQoS
IEEE 802.3az Energy-Efficient Ethernet (EEE)
CSMA/CD
Power supply - External
ProductName - DGS-108
producer - D-Link
Producer - D-link
HERSTELLER - D-LINK
Manufacturer - D-Link
Producent: Nazwa producenta / importera - D-link
D-Link (Polska) Sp. z o.o.
ul. Mysikrólika 11a
02-809 Warszawa
ProducerCode - DGS-108/E
Manufacturer Code - DGS-108/E
Manufacturer_code - DGS-108/E
Manufacturer Name - D-Link
Producer product name - DGS-108/E
Producer product family - Switch
Security - MAC address filtering - Yes
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Storno - Y
Switch class - Unmanaged
URL - https://www.dlink.co.uk/cs/Satellite?c=Product_C&childpagename=DLinkEurope-GB%2FDLProductCarouselMultiple&cid=1197392559038&p=1197356142823&packedargs=ParentPageID%3D1197335068935%26ProductParentID%3D1195808623774%26TopLevelPageProduct%3DBusiness%26categor
Power - Input voltage - 5 V
Power - Input current - 1 A
Power - Power consumption (typical) - 2.8 W
Network architecture - GigabitEthernet
Network - 10G support - Yes
Network - Auto MDI/MDI-X - Yes
Network - Full duplex - Yes
Network - Copper ethernet cabling technology - 1000BASE-T, 100BASE-TX, 10BASE-T
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Chassis type - Desktop
