D-Link DSS-200G-28MP/E, 24x1Gb PoE, 4xSPF

Brand - D-Link
BrandPartCode - DSS-200G-28MP
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Data transmission - Forwarding rate - 41.67 Mpps
Data transmission - Jumbo frames - 10240
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Number of queues - 4
Data transmission - Packet buffer memory - 4.1 MB
Data transmission - Switching capacity - 56 Gbit/s
Design - Form factor - 1U
Design - LED indicators - Activity, Alarm, Link, Power, Speed
Design - Number of fans - 2 fan(s)
Design - Product colour - Grey
Design - Reset button - Yes
EAN - 0790069471803
GTIN - 0790069471803
GTIN - 790069471803
LongDesc - Enjoy the Power of Next-Gen Surveillance SwitchEnhance your surveillance environment with the DSS-200G, a smart and easily installed device that delivers greater control and flexibility. Discover the capabilities of this intelligent tool that automates processes and adds intelligence to your network.Built for Surveillance,with Gigabit Ethernet & PoE++Designed to meet surveillance requirements for businesses of all sizes, with features like support for high-powered PTZ cameras, high PoE budgets, Auto Surveillance VLAN, and surge protection, these switches are ideal for IP surveillance setups. Long Range PoE DeliveryConnect and power cameras up to 250 metres away without the need for additional PoE extenders.Power Your DevicesSupports PoE/PoE+ to connect and power your PoE-cable network devices via Ethernet cables without the need for power adapters.Reliable PoE ConnectionsSurge protection on all PoE ports protects the switch when feeding power to PoE-capable devices.Rapid deployments with a single PoE cable.The series supports PoE, and some provide higher power PoE++, delivering up to 90 watts on selected ports, enabling faster deployment of PoE devices such as IP cameras, VoIP phones, access points, terminals, speakers, lights, conferencing systems, displays, and more. Reach further with a flick of a switch.The built-in DIP switch allows easy configuration and quick adjustment of application settings without the need to access the web configuration. Quickly enable and disable functions such as QoS, Extend (connection by up to 250 metres), Port Isolation, PD-Alive and STP (Spanning Tree Protocol) in an instant. Protects the network against power surges.6kV surge protection on all PoE ports protects the network against voltage spikes with link aggregation, ERPS and STP support to make your network more robust and resilient. Connect to more with PoE++See your remaining power availability with the built-in PoE Power Budget LEDs for 25%, 50%, 75%, and 100% power usage at a glance. And utilise up to 518W, with 90W on 8 ports and 30W on 15 ports for DSS-200G-28MPP, so you can rapidly deploy more devices. Layer 2 management features.Comes with a complete line-up of L2 features, including port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). Network maintenance features such as loopback detection and cable diagnostics. Quality of Service and bandwidth control.Bandwidth control allows network administrators to reserve bandwidth for important functions that require higher priority or more bandwidth.Auto Surveillance VLAN consolidates data and surveillance video transmission through a single switch, sparing businesses the expense of dedicated hardware and facilities.Voice VLAN enhances the VoIP service by automatically placing voice traffic from IP phones to a designated VLAN. With a prioritised and segmented VLAN, this feature guarantees quality and security of VoIP traffic.Energy efficientWith built-in D-Link Green technology, this series saves power without sacrificing operational performance or functionality.Time-Based PoESchedule the ports on the switch to provide PoE power to devices on specific days and during set hours of the week for energy savings Sleep modeLink status drastically reduces power consumption by automatically putting ports without a link into a sleep mode Advanced chipsetThe series incorporates a special chipset with advanced silicon technology for efficient use of energy We're here to help.Over 35 years in the networking industryInnovative end-to-end solution experts for small businesses to large corporations around the world.Talking to us is easySkilled local support in 16 countries. Our support teams are ready to help you.
LongProductName - 1U, Gigabit Ethernet, 24x 10/100/1000 Mbps PoE, 4x Combo 1000 Mbps, 41.67 Mpps, 8K Entries, PoE 370 W, DDR3 128 MB, 53 dB, 100-240 VAC, 50-60 Hz, Grey, 2.86 kg
LongSummaryDescription - D-Link DSS-200G-28MP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u,.... Power over Ethernet (PoE). Form factor: 1U
Management features - MIB support - • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention • RFC2233 Interface Group MIB • RFC2665 Ether-like MIB • RFC4363 IEEE 802.1p MIB • ZoneDefense MIB • Private MIB • RFC951 BootP client • RFC1542 BootP/DHCP client • RFC2236 IGMP Snooping
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Traffic classification - Yes
Management features - Web-based management - Yes
Manufacturer - D-Link
MPN - DSS-200G-28MP/E
Multicast features - Multicast features - Controllable multicast
Multicast features - Multicast support - Yes
Name - D-Link DSS-200G-28MP/E 28-Port Desktop Gigabit PoE Switch
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Network - Number of VLANs - 4094
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Operational conditions - Heat dissipation - 190.74 BTU/h
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Performance - Fanless - No
Performance - Flash memory - 32 MB
Performance - Internal memory - 128 MB
Performance - Mean time between failures (MTBF) - 331732 h
Performance - Memory type - DDR3-SDRAM
Performance - Noise level - 53 dB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Combo SFP ports quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 6.4 A
Power - Input voltage - 100 - 240 V
Power - Power consumption (max) - 425.9 W
Power - Power source - AC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 24
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 370 W
ProductName - DSS-200G-28MP
Security - IGMP snooping - Yes
Security - Password protection - Yes
Security - Queue scheduling algorithms - Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Security - SSH/SSL support - Yes
ShortSummaryDescription - D-Link DSS-200G-28MP, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), 1U
Sustainability - Sustainability compliance - Yes
Title - D-Link DSS-200G-28MP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
URL - https://www.dlink.com/en/products/dss-200g-28mp-28-port-10-100-1000-poe-gigabit-ethernet-surveillance-switch
WarrantyInfo - 5 years
Weight & dimensions - Depth - 208 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.86 kg
Weight & dimensions - Width - 440 mm
