Ubiquiti USW-Pro-Max-16, 12x1Gb, 4x2.5Gb, 2SFP

Category 1 - Netzwerk
2.5G Ethernet (copper) ports quantity Ports & interfaces - 4
Category 2 - Switching Hubs
Number of 10Gb ports - 2
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 12
10/100/1000/2500 Mbps ports - 4
10G support Network - Yes
Data transmission - Forwarding rate - 62 Mpps
Data transmission - Throughput - 42 Gbit/s
Data transmission - Switching capacity - 84 Gbit/s
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Static route - Yes
Data transmission - Jumbo frames support - Yes
Authentication type Security - IEEE 802.1x
Broadcast storm control Network - Yes
brand - Ubiquiti
Number of COMBO ports - None
DHCP features Security - DHCP guarding, DHCP relay, DHCP server, DHCP snooping
Design - Display type - LCM
Design - Housing material - SGCC
Design - LED indicators - Speed
Design - LED indicators - Link
Design - LED indicators - Status
Design - LED indicators - Network
Design - Rack mounting - Yes
Design - Reset button - Yes
Design - Product colour - Grey
Design - Stackable - Yes
Design - Form factor - 1U
EAN_code - 810084694565
Eans - 810084694565
Forwarding rate Data transmission - 62 Mpps
Forwarding rate - 62.496 MB/s
Display type Design - LCM
Housing material Design - SGCC
Power consumption - 25 W
Category_1 - Network and Servers
EAN - 0810084694565
Fan - No
guarantee - 12
Warranty - 12 months
guarantee_type - normal
warrantyLength - 24
warrantyType - G
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 12
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
CnCode - 85176200
mpn - USW-Pro-Max-16
IGMP snooping Security - Yes
IPv4 routes Network - 512
Management features - Switch layer - L3
Support for Jumbo frames - Yes
Jumbo frames support Data transmission - Yes
Access Control List (ACL) Security - Yes
Performance - Fanless - Yes
Cables included Packaging content - Power
Weight - 1.95 kg
Weight - 2,95
Weight - 2.996
weight - 3.5 kg
weight - 3040
Weight & dimensions - Weight - 1.95 kg
Weight & dimensions - Width - 325.1 mm
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 43.7 mm
Weight Weight & dimensions - 1.95 kg
Category - Root/Electronics/Networks and communication/Switchers
category - Mājas un biroju tīkli > Komutatori > 1G komutatori
Category Code - SWI
Category_2 - Network - Switches and Hubs
ean - 810084694565
Environment requirements - Temperature: -5 to 40° C Humidity: 10 to 90%, non-condensing
Description - A 16-port, Layer 3 Etherlighting™ switch 2.5 GbE and versatile mounting options.Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network*(4) 2.5 GbE RJ45 ports(12) GbE RJ45 ports(2) 10G SFP+ portsVersatile desktop, wall, and rack** mountingSilent, fanless cooling system
Description - The USW-Pro-Max-16 is a 16-port Layer 3 Etherlighting switch supporting 2.5GbE that offers versatile mounting options. Each port is equipped with Etherlighting illumination, making it easy to identify the port location, speed/link, and native VLAN. The switch has four 2.5GbE RJ45 ports, twelve GbE RJ45 ports, and two 10G SFP+ ports. Desktop, wall, or rack mount (requires additional rack mount accessories) makes it ideal for a variety of environments. Additionally, a quiet, fanless cooling system ensures reliable and discreet operation.
Gross Weight Kg - 5,4
vendpn - USW-Pro-Max-16
Summary - Ubiquiti Pro Max 16. Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 16000 entries, Switching capacity: 84 Gbit/s. Networking standards: IEEE 802.1x. Power connector: AC/DC. Rack mounting, Form factor: 1U
Accessories included -
Console port - No
Stackable Design - Yes
Stackability - No
Form factor Design - 1U
height - 0.132 m
Height Weight & dimensions - 43.7 mm
L2 features -
L3 features -
width - 0.25 m
Width Weight & dimensions - 325.1 mm
LED indicators Design - Link, Network, Speed, Status
Link aggregation Network - Yes
Throughput - 42 MB/s
Throughput Data transmission - 42 Gbit/s
ShortDescription -
Short description - Ubiquiti Switch UniFi 12xRJ45 GBit/4xRJ45 2.5G/2xSFP+ Managed Max optional 19" Rack-Mountable, 1,3" Touchscreen
Switch layer Management features - L3
Switching capacity Data transmission - 84 Gbit/s
MAC address table Data transmission - 16000 entries
MPN - USW-PRO-MAX-16
Model name - Pro Max 16
Model - USW-Pro-Max-16
Other functions -
Other features -
Designation - CE+WEEE
dimension height - 510 mm
dimension width - 110 mm
dimension depth - 250 mm
Dimensions - 325.1 x 160 x 43.7 mm
dimensionalWeight - 2832
dimension weight - 3000 g
Vendor Homepage - https://eu.store.ui.com/eu/en/pro/products/usw-pro-max-16
Name - 16+2P Ubiquiti UniFi USW-Pro-Max-16 M RM
name - Ubiquiti Switch USW-Pro-Max-16
Name - UBIQUITI USW-PRO-MAX-16
Name - Ubiquiti USW-Pro-Max-16, Switch
Reset button Design - Yes
Safety warning - Warnings - Follow the safety guidelines for electrical current.
Safety warning - Warnings - Make sure the ventilation of the equipment is not blocked.
Safety warning - Warnings - Avoid contact of the device with liquid.
Packaging content - Cables included - Power
Packaging content - Rack mount kit - Yes
Packet buffer memory Data transmission - 1.5 MB
title - Ubiquiti UniFi Switch Pro Max 16
length - 0.52 m
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 4
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 12
Ports & interfaces - Power connector - AC/DC
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - SFP+ module slots quantity - 2
Number of ports 25Gb - None
Port mirroring Network - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 16
Basic switching RJ-45 Ethernet ports type Ports & interfaces - 2.5G Ethernet (100/1000/2500)
Number of QSFP+ ports - None
Rack mount kit Packaging content - Yes
Rack mounting Design - Yes
Redundant power supply (RPS) support Power - Yes
Certificates - CE, FCC, IC
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - Industry Canada (IC)
Certificates - Compliance certificates - National Defense Authorization Act (NDAA)
SFP+ module slots quantity Ports & interfaces - 2
Number of SFP+ ports - 2
Number of SFP ports - None
Number of SFP56 ports - None
Loop protection Security - Yes
Input voltage Power - 4.8 - 5.2 V
Input current Power - 5 A
Heat dissipation Operational conditions - 85.3 BTU/h
Static route Data transmission - Yes
sizeZ - 250
sizeX - 515
Depth Weight & dimensions - 160 mm
Application - Home and small office
Quality of Service (QoS) support Management features - Yes
QoS -
Dane techniczne: Gwarancja - 1 rok w serwisie sprzedawcy
Dane techniczne: Zarządzalność - tak
Dane techniczne: Przeznaczenie - do szaf RACK 19"
Dane techniczne: Liczba portów LAN 2.5 Gbit - 4 szt.
Dane techniczne: Liczba portów LAN 10/100/1000 - 12 szt.
Dane techniczne: Warstwa przełączania - 3
Dane techniczne: Sloty SFP+ 10G - 2 szt.
Dane techniczne: Producent - Ubiquiti
Dane techniczne: Typ - zarządzalny
Dane techniczne: Obsługa VLANów - tak
sizeY - 110
Supported protocols and standards -
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power supply - Power supply method: Type-C adapter Power supply: 5V, 25W
Power supply - External
Power supply included Power - Yes
Power connector Ports & interfaces - AC/DC
productName - Ubiquiti Pro Max 16 L3 2.5G Ethernet (100/1000/2500) 1U Grey
productSize - Normal
Product colour Design - Grey
producer - UBIQUITI
Producer - Ubiquiti
Manufacturer - Ubiquiti
Producent: Nazwa producenta / importera - Ubiquiti
BATNA SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄ
Olgi Boznańskiej 3e
42-202 producerCode - USW-Pro-Max-16
ProducerCode - USW-PRO-MAX-16
Manufacturer Code - USW-PRO-MAX-16
Manufacturer_code - USW-Pro-Max-16
Manufacturer Name - Ubiquiti Networks
Security -
Security - Authentication type - IEEE 802.1x
Security - Loop protection - Yes
Security - DHCP features - DHCP relay
Security - DHCP features - DHCP guarding
Security - DHCP features - DHCP snooping
Security - DHCP features - DHCP server
Security - IGMP snooping - Yes
Security - Access Control List (ACL) - Yes
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -5 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Operational conditions - Heat dissipation - 85.3 BTU/h
Switch class - Managed
Compliance certificates Certificates - CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)
Fanless Performance - Yes
VLAN -
Virtual LAN features Network - Voice VLAN
Number of VLANs Network - 1000
VLAN support Network - Yes
Flow control support Network - Yes
Power - Input voltage - 4.8 - 5.2 V
Power - Input current - 5 A
Power - Power consumption (max) - 25 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Power consumption (max) Power - 25 W
Network architecture - GigabitEthernet
Rate limiting Network - Yes
Networking standards Network - IEEE 802.1x
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - IPv4 routes - 512
Network - Rate limiting - Yes
Network - Link aggregation - Yes
Network - Port mirroring - Yes
Network - Virtual LAN features - Voice VLAN
Network - Number of VLANs - 1000
Network - VLAN support - Yes
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.1x
Unit Calculated Volume - 0.0167344 cubm
Unit Calculated Weight - 3.4625 kg
Units per Shipping Box - 4
Unit Box Height - 0.245
Unit Box Width - 0.11
Unit Box Length - 0.51
Chassis type - Rack
