Accessories included -
Brand - ATEN
BrandPartCode - VS381B
Category - Video Switches
Color - Black
Connectors #1 - HDMI Type A Female
Connectors #2 - HDMI Type A Żeńska x3
Description - 3-portowy przełącznik HDMI VS381B True 4K z funkcją automatycznego przełączania umożliwia przełączanie 3 źródeł wejściowych HDMI na wyświetlacz HDMI. Obsługuje rozdzielczości wideo do True 4K (4096 x 2160 przy 60 Hz 4: 4: 4), szybkości transmisji danych do 18 Gb / s, HDR, 3D, Deep Color i bezstratne formaty audio HD. Ponadto VS381B oferuje metody przełączania między źródłami HDMI za pomocą przycisków na panelu przednim i pilota na podczerwień, umożliwiając użytkownikom bezproblemowe wybieranie żądanego wejścia. Diody LED Zasilanie 1 x LED (Green) Wyjście wideo 3 x LED (Green) Wejście wideo Interfejsy 3 x HDMI Type A Female (Black) Impedancja 100.0 om Maks. odległość Max 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) Wyjście wideo Interfejsy 1 x HDMI Type A Female (Black) Impedancja 100.0 om Maks. odległość Max 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) Wideo Maks. szybkość transmisji danych 18 Gbps (6 Gbps Per Lane) Maks. zegara pikseli 600 MHz Zgodność HDMI 2.0 (3D, Deep Color, 4K, HDR10, Dolby Vision) HDCP 2.2 Maks. rozdzielczość 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) Sterowanie IR 1 x Mini Stereo Jack Female (Black) / Max distance@ 5m Pobór mocy DC 5V/ 1.46W
Designation - CE+WEEE
dimension depth - 45 mm
dimension height - 160 mm
Dimensions - (D x S x W) 7.16 x 7.90 x 2.55 cm
dimension weight - 285 g
dimension width - 125 mm
ean - 4710469340383
Features - 3D - Yes
Features - Bandwidth - 18 Gbit/s
Features - Bandwidth - 600 MHz
Features - Dolby technologies - Dolby Vision
Features - External power adapter - Yes
Features - HDCP - Yes
Features - HDCP version - 2.2
Features - HD type - 4K Ultra HD
Features - Input impedance - 100 Ω
Features - Material - Metal
Features - Maximum operating distance - 5 m
Features - Maximum refresh rate - 60 Hz
Features - Maximum resolution - 4096 x 2160 pixels
Features - Plug and Play - Yes
Features - Product colour - Black
Features - Supported graphics resolutions - 3840 x 2160, 4096 x 2160
GTIN - 0672792012198
GTIN - 672792012198
GTIN - 4710469340383
guarantee - 24
guarantee_type - external
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The VS381B 3-Port True 4K HDMI Switch with Auto Switching provides you to switch 3 HDMI input sources to an HDMI display. It supports video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, HDR, 3D, Deep Color, and HD lossless audio formats. Furthermore, the VS381B offers switching methods between HDMI sources by front panel pushbuttons and IR remote control, enabling users to effortlessly select desired input.Featuring above functionalities provides you a practical solution for auditorium, home theater, meeting rooms, trade shows, shopping centers, and more.Package Contents- 1x VS381B 3-Port True 4K HDMI Switch- 1x USB to DC Power Cord- 1x IR Remote Control- 1x IR Receiver- 1x User Instructions
LongProductName - 3-Port True 4K HDMI Switch
LongSummaryDescription - ATEN 3-Port True 4K HDMI Switch. Video port type: HDMI. Material: Metal, Product colour: Black, Maximum refresh rate: 60 Hz. Power consumption (typical): 1.46 W. Width: 71.6 mm, Depth: 79 mm, Height: 25.5 mm
name - 3-Port True 4k HDMI Switch VS381B
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Środowiskowe Temperatura robocza 0 - 40 °C Temperatura przechowywania -20 - 60 °C Wilgotność 0 - 80% RH, Non-Condensing
Packaging content - AC adapter included - Yes
Ports & interfaces - 3.5 mm (1/8-inch) in - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - HDMI in - 3
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Number of HDMI outputs - 1
Ports & interfaces - Video port type - HDMI
Power - Power consumption (typical) - 1.46 W
producer - ATEN
ProductName - 3-Port True 4K HDMI Switch
ShortSummaryDescription - ATEN 3-Port True 4K HDMI Switch, HDMI, Metal, Black, 60 Hz, 5 m, 3840 x 2160, 4096 x 2160
Standard - HDMI Ultra HD 4K
System Requirements -
Title - ATEN 3-Port True 4K HDMI Switch
Type - Splitter
URL - https://www.aten.com/global/en/products/professional-audiovideo/video-switches/vs381b/
Usage - Video
vendpn - VS381B
WarrantyInfo -
Weight - 0.15 kg
Weight & dimensions - Depth - 79 mm
Weight & dimensions - Height - 25.5 mm
Weight & dimensions - Weight - 150 g
Weight & dimensions - Width - 71.6 mm
