Eaton 3S550D, 550VA 330W

Accessories included - Dołączony przewód zasilający. Kabel USB. Skrócona instrukcja obsługi. Instrukcje bezpieczeństwa.
ACoutletsquantity - 6 AC outlet(s)
ACoutlettypes -
Active power - 330 W
Apparent power - 550 VA
ARTIKEL1 - EATON 3S 550 DIN
ARTIKEL2 - .
AutomaticVoltageRegulationAVR -
Battery -
Battery - Automatic battery test - Yes
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Typical backup time at full load - 3 min
Battery - Typical backup time at half load - 9 min
Batterycapacity -
Batterytechnology - Sealed Lead Acid (VRLA)
Batteryvoltage -
Cablesincluded -
Category Code - UPW
Certificates > Certification - CE, EAC, IEC/EN 62040-1, IEC/EN 62040-2
Chassis type - Tower
Code - 3S550D
Color - Black
Color - White
Depth - 140 mm
Description -
Description - Eaton 3S 550VA UPS 230V
Design -
Design - Certification - IEC 62040-2
Design - Form factor - Mini Tower
Design - LED indicators - Yes
Design - Product colour - Black
Design - Safety - IEC/EN 62040-1-1, CE
Design > Form factor - Tower
Designation - CE+WEEE
dimensionalWeight - 2528
dimension depth - 190 mm
dimension height - 390 mm
Dimensions - 83.5 x 140 x 325 mm
Dimensions - 140 x 86 x 325 mm
dimension weight - 3988 g
dimension width - 165 mm
Displaytype -
EAN - 743172101754
ean - 743172101754
EANCode - 0743172101754
Efficiency -
Environment requirements -
Features -
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 284 V
Features - Input operation voltage (min) - 161 V
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 330 W
Features - Output power capacity - 0.55 kVA
Features - Surge protection features - Fax
Features - Surge protection features - Modem
Features - Surge protection features - Network
Features - Surge protection features - Telephone
Features > Colour of product - Black/White
Filters / protection - Surge
Formfactor -
Gewicht - 3.97
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 86 mm
HERSTELLER - EATON
HighLights -
Hotswapbattery - No
HSTNUMMER - 3S550D
Inputfrequency - 50/60 Hz
Inputoperationvoltagemax - 284 V
Inputoperationvoltagemin - 161 V
Input power ports - Wtyczka sieciowa
Link - https://www.eaton.com/pt/en-gb/skuPage.3S550D.html
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
ManufDatasheet -
Name - Eaton | UPS | 3S 550 DIN | 550 VA | 330 W
name - UPS 3S 550 DIN 3S550D 550VA 330W
Networkcardslot -
Noiselevel -
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude - 0 - 3000 m
OperatingrelativehumidityHH -
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features -
Other features - Compatible operating systems - Windows XP, Vista, 7
Linux
Mac OS X
Other features - Mac compatibility - Yes
Outputfrequency - 50 Hz
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 220 V
Outputpower - 330 W
Outputpowercapacity - 0.55 kVA
Output power capacity, VA - 550 VA
Output power capacity, W - 330 Watts
Output power ports - 6 x C/F type (Schuko)
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 393 mm
Package features > Gross height (mm) - 160.00 mm
Package features > Gross width (mm) - 195 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 141 pc(s)
Package features > Paper/Pasteboard - 600.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.70 kg
Package features > TI weight (kg) - 2.50 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.0122616 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Performance > Capacity - 550 VA
Performance > UPS topology - Off line
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - Type F
Ports & interfaces - USB 2.0 ports quantity - 1
Portsinterfaces -
Powerfactor -
Powerplug -
ProdDesc - Eaton 3S 550 UPS DIN
producer - Eaton
producerCode - 3S550DIN
Producer product family - UPS
Producer product name - 3S 550 DIN
Productcolour - Black, White
Productcondition - Original
ProductHighLights -

• Eaton 3S supplies battery backup power during outage and advanced surge protection to prevent damage from lightning strikes or accidental grid surge

productName - Eaton 3S 550 DIN 0.55 kVA 330 W 6 AC outlet(s)
Product Net Weight - 2.9 kg
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/3S550D_1.jpg
ProductPicture1 -
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
productSize - Normal
Quickinstallationguide -
Rackmountkit -
RS232ports -
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
sizeX - 160
sizeY - 395
sizeZ - 200
Software -
Special functions -
Stck_Kart - 9998
Stck_Pal - 8
Storno - Y
Technical details > Capacity - 330 W
Technical details > Gross weight - 3.90 kg
Technical details > Net weight - 3.20 kg
Technical details > Other features - Software compatibility: Eaton UPS Companion (enables safe system shutdown, energy usage metering and configuration of UPS settings)
Technical details > Producer - Eaton
Topology - Offline
Typicalbackuptimeathalfload -
Unit Box Height - 0.16
Unit Box Length - 0.39
Unit Box Width - 0.19
Unit Calculated Volume - 0.01186 cubm
Unit Calculated Weight - 4 kg
Units per Shipping Box - 1
UPStopology - Standby (Offline)
USBport - No
USBporttype -
Vendor Homepage - www.eaton.com
vendpn - 3S550D
Warranty - 12 months
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Warrantyandmisc -
warrantyLength - 24
warrantyType - F
Waveform -
Weight - 3.1 kg
Weight - 3.2 kg
weight - 3900
Weight & dimensions - Depth - 335 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.9 kg
Weight & dimensions - Width - 140 mm
Weightdimensions -
Width - 325 mm
