Eaton 5SC1000IR, 1000VA 700W, IEC 2U

Accessories included -
ACoutletsquantity - 8 AC outlet(s)
ACoutlettypes - C13 coupler
Active power - 700 W
Apparent power - 1000 VA
ARTIKEL1 - EATON 5SC 1000I RACK2U
ARTIKEL2 - IN
AutomaticVoltageRegulationAVR -
Battery -
Batterycapacity -
Batterytechnology -
Batteryvoltage -
Breite - 0.55
Cablesincluded -
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category Code - UPW
Certificates > Certification - UL 1778, IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC, cTUVus
Chassis type - Rack
Code - 5SC1000IR
Color - Black
Colour - Black
Depth - 405 mm
Description -
Description - Eaton 5SC 1000 VA Rack 2U The Eaton 5SC UPS provides line-interactive, affordable and reliable protection for small business server in any kind of installation constraints. Complementing our range of industry leading UPSs, the 5SC includes an LCD interface for real-time status and measurements, implements manageability solutions compatible with most of IT platforms and provides sinewave output for compatibility with most sensitive IT equipments.
Design -
Design > Form factor - Rack
Designation - CE+WEEE
dimension depth - 240 mm
dimension height - 570 mm
Dimensions - 86.2 x 440 x 405
dimension weight - 19100 g
dimension width - 540 mm
Displaytype -
EAN - 743172088321
ean - 7431720883216
EANCode - 0743172088321
Eans - 743172088321
Efficiency -
Environment requirements -
Features -
Features > Colour of product - Black
Formfactor - Rackmount
Gewicht - 19.64
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 86.2 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0.23
Hotswapbattery -
HSTNUMMER - 5SC1000IR
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB 2.0
Inputfrequency - 45/55 Hz
Inputoperationvoltagemax - 276 V
Inputoperationvoltagemin - 184 V
Input ports - Single, IEC320 C14 (10AMP)
Input power ports - IEC-C14
Laenge - 0.58
Link - https://www.eaton.com/fr/en-gb/skuPage.5SC1000IR.html
LongDesc -
ManufDatasheet -
name - 5SC 1000i Rack2U 5SC1000IR
Name - Eaton 5SC 1000i Rack2U
Name - Eaton | UPS | 5SC 1000i Rack2U | 1000 VA | 700 W
Networkcardslot -
No. of batteries - 1
Noiselevel - 45 dB
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features -
Other features > Special features - Automatic Voltage Regulation (AVR); Delivers clean sinewave output; LCD display for real-time status and measurements; Reliable and affordable UPS for rack servers, networking and storage; Compatible with 500 mm depth enclosures; 1 slot for optional com card (Network management card, Relay card or Network and Industrial card); Compatible with Virtual environments (VMware, Hyper-V, Citrix Xen, Redhat); Fully integrates with Eaton Intelligent Power Manager software; 1 USB port + 1 serial port; Advanced Battery Management (ABM) technology to increase battery lifetime; Hot swappable batteries; Remote ON/OFF and remote Power OFF connectors; Cable locking system
Outputfrequency - 50/60 Hz
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 220 V
Outputpower - 700 W
Outputpowercapacity - 1 kVA
Output power capacity, VA - 1000 VA
Output power capacity, W - 700 Watts
Output power connector type - IEC 320 C13
Output power ports - 8 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 575 mm
Package features > Gross height (mm) - 235 mm
Package features > Gross width (mm) - 545 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 23 pc(s)
Package features > Paper/Pasteboard - 3500.00 g
Package features > Plastic (No PET) - 600.00 g
Package features > Tare weight (kg) - 4.10 kg
Package features > TI weight (kg) - 13.00 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.073643125 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Performance > Capacity - 1000 VA
Performance > UPS topology - Line-Interactive
Portsinterfaces -
Powerfactor -
Powerplug - C14 coupler
ProdDesc - Eaton 5SC 1000i Rack2U
producer - Eaton
Producer - Eaton
ProducerCode - 5SC1000iR
Producer product family - UPS
Producer product name - 5SC 1000i Rack2U
Productcolour - Black
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 1 kVA 700 W
• 8 AC outlet(s)
• Rackmount Black

Product Net Weight - 14.96 kg
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/5SC1000IR_1.jpg
ProductPicture1 -
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide -
Rack 2U Mounting Type - Yes
Rackmountkit -
RS232 Communication ports - 1
RS232ports - 1
Serialinterface - Yes
Serialinterfacetype - RS-232
Serialportsquantity -
ShortDescription -
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storno - Y
Technical details > Capacity - 700 W
Technical details > Gross weight - 19.5 kg
Technical details > Net weight - 15.4 kg
Technical details > Producer - Eaton
Topology - LineInteractive
Typicalbackuptimeathalfload -
Unit Box Height - 0.235
Unit Box Length - 0.54
Unit Box Width - 0.575
Unit Calculated Volume - 0.07297 cubm
Unit Calculated Weight - 19 kg
Units per Shipping Box - 1
UPS Architecture - line-interactive
UPStopology - Line-Interactive
USB Communication ports - 1
USBport - Yes
USBporttype -
Vendor Homepage - powerquality.eaton.com/5SC1000iR.aspx?cx=13&GUID=E166D4D1-68A2-40B2-A7B6-B8B940ADAA89
vendpn - 5SC1000IR
Video -
Warranty - 12 months
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Warrantyandmisc -
Waveform -
Wave form type - Pure sinewave
Weight - 14.96 kg
Weight - 15 kg
Weightdimensions -
Width - 440 mm
