Alarm - -
ARTIKEL1 - EATON ELLIPSE ECO 1600 USB DIN
ARTIKEL2 - IN
BatteryType - Replaceable sealed lead acid
Code - EL1600USBDIN
Color - -
ControlPanel - -
Depth - 312 mm
EAN - 3553340621628
EANCode - 3553340621628
FormFactor - Other
GrossWeight - 8.800 kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
Height - 305 mm
HERSTELLER - EATON
HSTNUMMER - EL1600USBDIN
InputConnections - -
InputFrequency - 50-60 Hz autoselect
InputVoltage - 184 V - 264 V (adjustable to 161 V - 284 V)
InterfacePorts - -
Laenge - 0.4
LongDesc - With an efficient electrical design and the EcoControl function (USB models), which automatically disables peripherals when the master device is turned off, the Eaton Ellipse ECO helps you make energy savings of up to 25 per cent compared to previous-generation UPSs.
MANUFDATASHEET - http://www.google.ee/url?sa=t&rct=j&q=&esrc=s&frm=1&source=web&cd=1&cad=rja&ved=0CCgQFjAA&url=http%3A%2F%2Flit.powerware.com%2Fll_download.asp%3Ffile%3DEaton-Ellipse-ECO-datasheet-rev-B-low-pdf.pdf&ei=RuKAUpzhBsPNhAf2mYHIDg&usg=AFQjCNHHroTtcgPB-33mgzDEb-J4xFyDpg&bvm=bv.56146854,d.bGE
Name - Eaton Ellipse ECO UPS USB DIN, 1600 VA, 1000 W, Input: C14, Outputs: (4) Schuko, (4) Schuko surge only, Tower | Eaton
OutputConnections - 8
OutputFrequency - -
OutputVoltage - 230 V (adjustable to 220 V, 230 V, 240 V
PackageContents - -
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 81.00 mm
Package features > Gross height (mm) - 312.00 mm
Package features > Gross width (mm) - 305.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 112 pc(s)
Package features > Paper/Pasteboard - 900.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 1.00 kg
Package features > TI weight (kg) - 5.00 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
PowerVAW - 1600 VA
PowerW - 1000 W
ProdDesc - 1600VA/1000W UPS, offline, DIN 4+4, Windows/MacOS/Linux support, USB
ProductPicture - http://www.tdbaltic.ee/images/ds4/EL800USBIEC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - -
RJ45 - -
Runtime - 11/6
SmartSlot - -
Stck_Kart - 9998
Stck_Pal - 1
Storno - N
Technical details > Gross weight - 8.80 kg
Technical details > Net weight - 7.80 kg
Technical details > Producer - Eaton
Topology - Offline
USB - Yes
Warranty - 2 years
Warranty - 24
Warranty - 24 month(s)
WaveformType - -
Weight - 7.800 Kg
Width - 81 mm
