Battery - Battery capacity - 9 Ah
Battery - Battery recharge time - 9 h
Battery - Battery voltage - 12 V
Battery - Charging current - 1 A
Battery - Number of batteries supported - 20
Battery - Typical backup time at full load - 2.8 min
Battery - Typical backup time at half load - 8.4 min
Design - Cooling type - Active
Design - Display type - LCD
Design - Form factor - Tower
Design - LED indicators - Yes
Design - Product colour - Black
dimensionalWeight - 33779
Features - Crest factor - 3:1
Features - Efficiency - 94%
Features - Emergency Power Off (EPO) - Yes
Features - Hold time (max) - 0 ms
Features - Input frequency - 46/64 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 110 V
Features - Input power factor - 0.99
Features - Noise level - 58 dB
Features - Output frequency regulation - -0.1 - 0.1 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 208 V
Features - Output power - 10000 W
Features - Output power capacity - 10 kVA
Features - Output power factor - 1
Features - Output voltage regulation - -1 - 1%
Features - Response time - 0 ms
Features - UPS topology - Double-conversion (Online)
Logistics data - Harmonized System (HS) code - 85078000
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - I/O ports - Intelligent Slot
Packaging content - Cables included - USB cable
Packaging content - Manual - Yes
Packaging data - Package depth - 570 mm
Packaging data - Package height - 785 mm
Packaging data - Package weight - 88 kg
Packaging data - Package width - 310 mm
Packaging data - Resource CD - Yes
Ports & interfaces - AC outlets quantity - 1 AC outlet(s)
Ports & interfaces - AC outlet types - Terminal
Ports & interfaces - Emergency Power Off (EPO) connector - Yes
Ports & interfaces - Power plug - Terminal
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - USB 2.0 ports quantity - 1
producerCode - VFI 10000 CG PF1
productName - PowerWalker VFI 10000 CG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W 1 AC outlet(s)
productSize - SmallPallet
sizeX - 580
sizeY - 910
sizeZ - 320
warrantyLength - 24
warrantyType - G
weight - 80500
Weight & dimensions - Depth - 592 mm
Weight & dimensions - Height - 576 mm
Weight & dimensions - Weight - 83 kg
Weight & dimensions - Width - 250 mm
