Incase True 4K HDMI Switch VS481C 4-port

Accessories included - Zasilacz IR Remote Control Unit Kabel HDMI Instrukcja użytkownika
Brand - ATEN
BrandPartCode - VS481C-AT-G
Category - Video Switches
Code - VS481C-AT-G
Color - Black
Description - ATEN VS481C
4-portowy przełącznik HDMI True 4K
VS481C firmy ATEN jest zaprojektowany dla aplikacji wymagających 4 źródła dla jednego bezprzewodowego kompatybilnego wyświetlacza. Umożliwia on niezawodną transmisję sygnału w rozdzielczości do True 4K (4096 x 2160 @ 60Hz 4:4:4), szybkość transmisji danych do 18 Gb/s, 3D, Deep Color aż do12-bit, i bezstratne formaty audio HD. Posiada również funkcje przyjazne dla integratora, m.in. Auto Switching dla automatycznego wyboru portu, Instant Switching dla płynnej transmisji wideo pomiędzy portami HDMI, dwukierunkowy RS-232 i IR do zdalnego sterowania urządzeniami.
VS481C firmy ATEN zaprojektowany z myślą o dzisiejszym zapotrzebowaniu na transmisję sygnału True 4K i zorientowany na użytkownika, jest potężnym urządzeniem dla takich rozwiązań jak kina domowe, sale konferencyjne, targi i centra handlowe.
Designation - CE+WEEE
dimension depth - 60 mm
dimension height - 240 mm
Dimensions - 20.00 x 8.21 x 2.50 cm
dimension weight - 800 g
dimension width - 160 mm
EAN - 4719264646270
ean - 4719264646270
Features - 3D - Yes
Features - Bandwidth - 18 Gbit/s
Features - Bandwidth - 600 MHz
Features - Colour depth - 12 bit
Features - Consumer Electronics Control (CEC) support - Yes
Features - HDCP - Yes
Features - HDCP version - 2.2
Features - HD type - HD
Features - Input impedance - 100 Ω
Features - LED indicators - Yes
Features - Material - Metal
Features - Maximum operating distance - 3 m
Features - Maximum refresh rate - 60 Hz
Features - Maximum resolution - 4096 x 2160 pixels
Features - Output impedance - 100 Ω
Features - Plug and Play - Yes
Features - Product colour - Black
GTIN - 0672792008221
GTIN - 672792008221
GTIN - 4719264646270
guarantee - 24
guarantee_type - external
Inputs - 1 x RS-232
Inputs - 4 x HDMI
Link - https://www.aten.com/global/en/products/professional-audiovideo/video-switches/vs481c/
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Master (outer) case gross weight - 8.57 kg
Logistics data - Master (outer) case height - 178 mm
Logistics data - Master (outer) case length - 490 mm
Logistics data - Master (outer) case net weight - 6.54 kg
Logistics data - Master (outer) case width - 315 mm
Logistics data - Products per master (outer) case - 10 pc(s)
LongDesc - The ATEN VS481C is designed for applications that require the routing of 4 sources to one compatible display device. It enables the reliable transmission at video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, 3D, Deep Color up to 12-bit, and HD lossless audio formats. Integrator-friendly features include Auto Switching modes for auto port selection, bi-directional RS-232, and IR for remote device control. Engineered to meet today's demand of True 4K signal transmission and user- oriented design, the ATEN VS481C is a powerful solution for a wide range of settings, such as home theater, meeting rooms, trade shows, and shopping centers.1x VS481C 4-Port True 4K HDMI Switch1x 0AD6-1005-10AG Power Adapter1x 2XRT-0101G IR Remote Control Unit1x LIN5-19V2-V21G HDMI Cable1x User Instructions
LongProductName - 4-Port True 4K HDMI Switch
LongSummaryDescription - ATEN 4-Port True 4K HDMI Switch. Video port type: HDMI. Material: Metal, Product colour: Black, Maximum refresh rate: 60 Hz. Power consumption (typical): 0.924 W. Width: 82.1 mm, Depth: 200 mm, Height: 25 mm. Package width: 59 mm, Package depth: 239 mm, Package height: 160 mm
name - 4-Port True 4K HDMI Switch VS481C-AT-G
Name - Aten | True 4K HDMI Switch | VS481C | 4-port
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features -
Outputs - 1 x 2,5mm minijack
Outputs - 1 x HDMI
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 200 mm
Package features > Gross height (mm) - 25 mm
Package features > Gross width (mm) - 82.1 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 31 pc(s)
Package features > Paper/Pasteboard - 2000.00 g
Package features > Plastic (No PET) - 30.00 g
Package features > Tare weight (kg) - 2.03 kg
Package features > Volume (m3) - 0.0004105 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 239 mm
Packaging data - Package height - 160 mm
Packaging data - Package weight - 822 g
Packaging data - Package width - 59 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - HDMI in - 4
Ports & interfaces - HDMI ports quantity - 5
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - Number of HDMI outputs - 1
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - Video port type - HDMI
Ports & interfaces > Video port type - 4-port
Power - Power consumption (typical) - 0.924 W
producer - ATEN
Producer product family - True 4K HDMI Switch
Producer product name - VS481C
ProductName - 4-Port True 4K HDMI Switch
ShortSummaryDescription - ATEN 4-Port True 4K HDMI Switch, HDMI, Metal, Black, 60 Hz, 3 m, 18 Gbit/s
Special functions -
Technical details > Gross weight - 2.5 kg
Technical details > Net weight - 0.47 kg
Technical details > Producer - Aten
Title - ATEN 4-Port True 4K HDMI Switch
URL - https://www.atten.eu/
vendpn - VS481C-AT-G
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight - 0.47 kg
Weight & dimensions - Depth - 200 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Weight - 654 g
Weight & dimensions - Width - 82.1 mm
