ACoutletsquantity - 42 AC outlet(s)
ACoutlettypes - C13 coupler, C19 coupler
ACinputfrequency - 50 - 60 Hz
Stck_Pal - 0
Data Act - Link
ARTIKEL1 - EASY PDU BASIC ZERO U 22KW
ARTIKEL2 - 230V (30) C13AND(12) C19 IEC309
Brand - APC
BrandPartCode - EPDU1232B
No. of C13 sockets - 30
No. of C19 sockets - 12
Design -
Design - Mounting - Vertical
Design - PDU types - Basic
Design - Rack capacity - 0U
Design - Product colour - Black
Design - Type - Three-phase
EANCode - 0731304405061
Formfactor -
guarantee - 12
Warranty - 12 months
PeriodofWarranty - 2 Y
WarrantyInfo - 1 year repair or replace
Warrantyandmisc -
guarantee_type - external
GTIN - 0731304405061
GTIN - 731304405061
GRUPPE1 - Power Protection
GRUPPE2 - Power Product Cpnt
HSTNUMMER - EPDU1232B
Cablecolour -
Cablelength - 2 m
Cable length - 2 m
Weight - 5.14 kg
Weight - 5.14 kg
Weight - 6.150000
Weight, kg - 5.14
Weightdimensions -
Weight & dimensions - Weight - 5.14 kg
Weight & dimensions - Width - 62 mm
Weight & dimensions - Depth - 44 mm
Weight & dimensions - Height - 1794 mm
Category - Power Distribution Units (PDUs)
ean - 731304405061
Description - APC EASY PDU, BASIC, ZERO U, 22 KW, 230V, (30) C13 & (12) C19?IEC309
Description - Green PremiumTM label is Schneider Electrics commitment to delivering products with best-in-class environmental performance. Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products.
vendpn - EPDU1232B
Accessories included - Installation guide Toolless mounting kit Vertical mounting brackets
Height - 110.000000
Height - 1794 mm
Height, mm - 1794
Width - 62 mm
Width - 160.000000
Width, mm - 62
LEDindicators -
Logistics data - Total carbon footprint (kg of CO2e) - 127.67
ShortSummaryDescription - APC Easy Rack PDU, Basic, 0U, 3 Phase, 22kW, 230V, 32A, 30 x C13 and 12 x C19 outlets, IEC60309 3P+N+PE inlet, Basic, 0U, Three-phase, Vertical, Black, 42 AC outlet(s)
Maximuminputcurrentperphase - 32 A
Maximumcurrent - 32 A
Maximumpower - 22000 W
Other features - Output voltage: 230V Input current: 32 A Input socket type: IEC 309 32A 3P + N + PE
Designation - CE+WEEE
dimension height - 160 mm
dimension width - 110 mm
dimension depth - 1950 mm
Dimensions - 179,4 x 6,2 x 4,4 cm
dimension weight - 6200 g
name - EPDU1232B PDU Easy Basic 0U,22kW,30xC13,12xC19
Nominaloutputvoltage - 230 V
Nominal output voltage, V - 230
Nominalinputvoltage - 400 V
Nominal input voltage, V - 400
Features -
Features - Cable length - 2 m
Mounting - Rack
Mounting - Wall
Mounting - Vertical
Packaging data - Package weight - 6.2 kg
Packaging data - Package height - 1950 mm
Packaging data - Package width - 160 mm
Packaging data - Package depth - 110 mm
Packagingcontent -
Packaging content - Manual - Yes
Packagingdata -
PDUtypes - Basic
Title - APC Easy Rack PDU, Basic, 0U, 3 Phase, 22kW, 230V, 32A, 30 x C13 and 12 x C19 outlets, IEC60309 3P+N+PE inlet
LongDesc -
LongDesc - APC Easy Basic Rack PDU EPDU1232B is Easy-to-install and easy-to-use PDU, making rack power distribution easy. This offers more than a power strip for server rack and network rack solutions. This is Vertical rack mountable PDU in ultra light weight upto 50% weight reduction with Aluminum housing. This is integrated with Hydraulic-magnetic circuit breakers (in units with 32A input current). EPDU1216B has IEC 309 32A 3P+N+E type inlet, Thirty IEC C13 and twelve IEC C19 type outlet sockets. This can operate from -5° to +45°C temperation range and comes with 1 year of standard warranty. Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. The packaging includes installation guide, toolless mounting kit and mounting brackets for quick and easy mounting in the rear of the enclosure. Saves time and money during installation by using one branch whip and standard connections. Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements.
LongSummaryDescription - APC Easy Rack PDU, Basic, 0U, 3 Phase, 22kW, 230V, 32A, 30 x C13 and 12 x C19 outlets, IEC60309 3P+N+PE inlet. PDU types: Basic, Rack capacity: 0U, Type: Three-phase. AC outlets quantity: 42 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC 60309. Cable length: 2 m. Nominal input voltage: 400 V, Maximum current: 32 A, AC input frequency: 50 - 60 Hz. Certification: CE, TUV
LongProductName - Easy Rack PDU, Basic, 0U, 3 Phase, 22kW, 230V, 32A, 30 x C13 and 12 x C19 outlets, IEC60309 3P+N+PE inlet
Length - 1950.000000
Ports & interfaces - AC outlets quantity - 42 AC outlet(s)
Ports & interfaces - Power plug - IEC 60309
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Portsinterfaces -
ProdDesc - Easy PDU, Basic, Zero U, 22 kW, 230V, (30) C13 & (12) C19?IEC309
Rackmounting -
Rackmountkit -
Rackcapacity - 0U
Certificates - Certification - CE, TUV
Input frequency, Hz - 50/60
Stck_Kart - 1
Storage temperature range (T-T), °C - -25 - 65
Depth - 44 mm
Depth, mm - 44
Powerplug - IEC 60309
ProductHighLights -
- Three-phase Basic 0U Black
- 42 AC outlet(s) C13 coupler, C19 coupler
- 22000 W
ProductName - Easy Rack PDU, Basic, 0U, 3 Phase, 22kW, 230V, 32A, 30 x C13 and 12 x C19 outlets, IEC60309 3P+N+PE inlet
ProductPicture - https://www.tdbaltic.ee/images/products/APC/EPDU1232B_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/APC/EPDU1232B_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/APC/EPDU1232B_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/APC/EPDU1232B_4.jpg
ProductPicture4 -
ProductPicture5 -
Productcondition - Original
Productcolour - Black
Manufacturer - APC
producer - APC
HERSTELLER - APC
ManufDatasheet -
ManufacturerPartNumber - EPDU1232B
HighLights -
Operating relative humidity range, % - 5-95
Operating temperature range (T-T), °C - -5-45
OperatingtemperatureTT - -5 - 45 °C
Operationalconditions -
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -25 - 65 °C
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -5 - 45 °C
Storno - N
Type - Three-phase
URL - https://www.apc.com/
Outputconnections -
Color - Black
Power -
Power - Load capacity - 22080 VA
Power - Maximum current - 32 A
Power - Maximum power - 22000 W
Power - Nominal output voltage - 230 V
Power - Nominal input voltage - 400 V
Power - AC input frequency - 50 - 60 Hz
Power - Maximum input current per phase - 32 A
