Aktsia sihtmärk - 0
ARTIKEL1 - 5-PORT USB PCIe KAART 10GBPS
ARTIKEL2 -
Bränd - StarTech.com
Brändi osade kood - PS4C3IA3-USB-C-CARD
Disain - Sisemine - Jah
Disain - Toote värv - Must
EAN-kood - 0065030909174
Funktsioonid - UASP tugi - Jah
Garantiiinfo - 2-aastane garantii
Globaalne kaubakood - 0065030909174
Globaalne kaubakood - 065030909174
GRUPPE1 - Võrk
GRUPPE2 - USB-jaoturi / kontroller
HST NUMBER - PS4C3IA3-USB-C-CARD
Kaal - 0.16
Kaal ja mõõtmed - Kaal - 60 g
Kaal ja mõõtmed - Laius - 121 mm
Kaal ja mõõtmed - Sügavus - 122 mm
Kaal ja mõõtmed – Kõrgus - 22 mm
Kategooria - Liidesekaardid/adapterid
Kuidas sul läheb? - 0
Laenge - 0
laius - 0
Logistikaandmed – peamine (välimine) kasti kõrgus - 315 mm
Logistikaandmed – peamine (välimine) kasti laius - 370 mm
Logistikaandmed – peamine (välimine) kasti pikkus - 440 mm
Logistikandmed – tooted ühe peamise (välimise) kasti kohta - 40 tükki
Lühikokkuvõte - StarTech.com 5-portiline USB PCIe-kaart, USB 3.2 10 Gbps, PCI Express-kaart 4 USB-C-porti, 1 USB-A siseport, USB PCIe-kontrollerkaart, Windows/macOS/Linux, PCIe, USB Type-C, täiskõrgusega / madal profiil, PCI 3.0, SATA 15-pin, must
Omadused - Kiibistik - ASMEDIA – ASM3142, VIA LABS – VL822
Pakendi andmed - Kiirpaigaldusjuhend - Jah
Pakendi andmed - Kinnitusklambrid kaasas - Jah
Pakendi andmed - Pakendi kaal - 156 g
Pakendi andmed - Pakendi kõrgus - 35 mm
Pakendi andmed - Pakendi laius - 142 mm
Pakendi andmed - Pakendi sügavus - 210 mm
Pealkiri - StarTech.com 5-portiline USB PCIe-kaart, USB 3.2 10 Gbps, PCI Express-kaart 4 USB-C-porti, 1 USB-A siseport, USB PCIe-kontrollerkaart, Windows/macOS/Linux
Pikk kirjeldus - Lisage PCIe-hostarvutisse neli USB Type-C (USB 3.2 Gen 2 10 Gbps) porti ja üks sisemine USB Type-A (10 Gbps) port. Uuendage või laiendage lauaarvuti või serveri USB-ühenduvust, lisades neli välist USB Type-C 10 Gbps porti ja ühe sisemise USB Type-A 10 Gbps porti ühe PCI Express x4 ühenduse kaudu.USB 3.2 Gen 2 (10 Gbps) jõudlusASM3142 kontroller toetab USB 3.2 ülekandekiirust kuni 10 Gbps, mis teeb selle ideaalseks suurte failide ülekandmiseks või kõrge resolutsiooniga fotode ja videote redigeerimiseks välistel salvestusseadmetel.USB-seadmete laadimine ja sünkroonimineSee USB PCIe laienduskort saab täiendavat toidet SATA toite kaudu, pakkudes kuni 5 V 3 A (15 W) USB Type-C pordi kohta ja 5 V 1,5 A (7,5 W) USB Type-A pordi kohta, kui emaplaadi toide on ebapiisav.ÜhilduvusPCI Express USB-kaardi draiverid installitakse automaatselt enamikus levinud operatsioonisüsteemides, sealhulgas Windows 8 ja uuemad versioonid, macOS ja Linux. See töötab selliste riistvaraplatvormidega nagu Intel, AMD ja Apple Silicon ning sobib PCI Express x4, x8 ja x16 pesadesse. Lisaks on USB-laienduskardil eelinstallitud standardprofiili kinnitus ja madala profiiliga kinnitus, mis tagab ühilduvuse väikese vormifaktoriga (SFF) lauaarvutite ja serveritega. StarTech.com eelis
Pikk kokkuvõte - StarTech.com 5-portiline USB PCIe-kaart, USB 3.2 10 Gbps, PCI Express-kaart 4 USB-C-porti, 1 USB-A siseport, USB PCIe-kontrollerikaart, Windows/macOS/Linux. Host-liides: PCIe, väljundliides: USB Type-C, laienduskardi vorm: täiskõrgusega / madalprofiiliga. Toote värv: must. Kiibistik: ASMEDIA - ASM3142, VIA LABS - VL822. Toetatud Windows-operatsioonisüsteemid: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Toetatud Mac-operatsioonisüsteemid: Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, ..., Toetatud serveri operatsioonisüsteemid: Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019. Laius: 121 mm, sügavus: 122 mm, kõrgus: 22 mm
Pikk tootenimi - StarTech.com 5-portiline USB PCIe-kaart, USB 3.2 10 Gbps, PCI Express-kaart 4 USB-C-porti ja 1 USB-A sisepordiga
Pordid ja liidesed - Host-liides - PCIe
Pordid ja liidesed - Laienduskardi standard - PCI 3.0
Pordid ja liidesed - Laienduskardi vorm - Täiskõrgusega / madal profiil
Pordid ja liidesed - Sisemised USB 3.2 Gen 2 (3.1 Gen 2) tüüpi A pordid - 1
Pordid ja liidesed - Väljundliides - USB tüüp C
Pordid ja liidesed – SATA toitepistik - SATA 15-pin
Pordid ja liidesed – USB 3.2 Gen 2 (3.1 Gen 2) Type-C pordid - 4
Stck_kaart - 9998
Süsteeminõuded - Toetatud Windows-operatsioonisüsteemid - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Süsteeminõuded – toetatavad serveri operatsioonisüsteemid - Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Süsteeminõuded – toetatud Linuxi operatsioonisüsteemid - Jah
Süsteeminõuded – toetatud Mac-i operatsioonisüsteemid - Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma
Tehnilised andmed - Vastavussertifikaadid - Ohtlike ainete piiramine
Toote nimi - 5-portiline USB PCIe-kaart, USB 3.2 10 Gbps, PCI Express-kaart 4 USB-C-portiga, 1 USB-A siseport, USB PCIe-kontrollerkaart, Windows/macOS/Linux
TOOTJA - STARTECH
Töötingimused - Ladustamistemperatuur (T-T) - -10 - 70 °C
Töötingimused - Töötemperatuur (H-H) - 5 - 90%
Töötingimused - Töötemperatuur (T-T) - 0 - 50 °C
Tühistamine - Ja
Veebiaadress - https://www.startech.com/en-us/PS4C3IA3-USB-C-CARD
Stck_Pal - 0
ARTIKEL1 - 5-PORT USB PCIE CARD 10GBPS
ARTIKEL2 -
Brand - StarTech.com
BrandPartCode - PS4C3IA3-USB-C-CARD
Design - Internal - Yes
Design - Product colour - Black
EANCode - 0065030909174
Features - UASP support - Yes
WarrantyInfo - 2-Year Warranty
GTIN - 0065030909174
GTIN - 065030909174
GRUPPE1 - Network
GRUPPE2 - USB Hub / Controller
HSTNUMMER - PS4C3IA3-USB-C-CARD
Gewicht - 0.16
Weight & dimensions - Weight - 60 g
Weight & dimensions - Width - 121 mm
Weight & dimensions - Depth - 122 mm
Weight & dimensions - Height - 22 mm
Category - Interface Cards/Adapters
Hoehe - 0
Laenge - 0
Breite - 0
Logistics data - Master (outer) case height - 315 mm
Logistics data - Master (outer) case width - 370 mm
Logistics data - Master (outer) case length - 440 mm
Logistics data - Products per master (outer) case - 40 pc(s)
ShortSummaryDescription - StarTech.com 5-Port USB PCIe Card, USB 3.2 10Gbps, PCI Express Card with 4x USB-C Ports, 1x USB-A Internal Port, USB PCIe Controller Card, Windows/macOS/Linux, PCIe, USB Type-C, Full-height / Low-profile, PCI 3.0, SATA 15-pin, Black
Features - Chipset - ASMEDIA - ASM3142, VIA LABS - VL822
Packaging data - Quick installation guide - Yes
Packaging data - Mounting brackets included - Yes
Packaging data - Package weight - 156 g
Packaging data - Package height - 35 mm
Packaging data - Package width - 142 mm
Packaging data - Package depth - 210 mm
Title - StarTech.com 5-Port USB PCIe Card, USB 3.2 10Gbps, PCI Express Card with 4x USB-C Ports, 1x USB-A Internal Port, USB PCIe Controller Card, Windows/macOS/Linux
LongDesc - Add four USB Type-C (USB 3.2 Gen 2 10Gbps) ports to a PCIe host computer, plus an internal USB Type-A (10Gbps) portUpgrade or expand a desktop or server's USB connectivity by adding four external USB Type-C 10Gbps ports and one internal USB Type-A 10Gbps port via a single PCI Express x4 connection.USB 3.2 Gen 2 (10Gbps) PerformanceThe ASM3142 controller supports USB 3.2 transfer speeds of up to 10Gbps, making it ideal for transferring large files or editing high-resolution photos and videos on external storage devices.Charge and Sync USB DevicesThis USB PCIe expansion card can receive supplemental power through SATA power, providing up to 5V 3A (15W) per USB Type-C port and 5V 1.5A (7.5W) on the USB Type-A port when motherboard power is insufficient.CompatibilityThe PCI Express USB card drivers auto-install in most major operating systems, including Windows 8 and up, macOS, and Linux. It works with hardware platforms such as Intel, AMD, and Apple Silicon and fits in PCI Express x4, x8, and x16 slots. Additionally, the USB expansion card comes with a pre-installed standard profile bracket and includes a low-profile bracket for compatibility with small form factor (SFF) desktops and servers.The StarTech.com Advantage
LongSummaryDescription - StarTech.com 5-Port USB PCIe Card, USB 3.2 10Gbps, PCI Express Card with 4x USB-C Ports, 1x USB-A Internal Port, USB PCIe Controller Card, Windows/macOS/Linux. Host interface: PCIe, Output interface: USB Type-C, Expansion card form factor: Full-height / Low-profile. Product colour: Black. Chipset: ASMEDIA - ASM3142, VIA LABS - VL822. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Mac operating systems supported: Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur,..., Server operating systems supported: Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019. Width: 121 mm, Depth: 122 mm, Height: 22 mm
LongProductName - StarTech.com 5-Port USB PCIe Card, USB 3.2 10Gbps, PCI Express Card with 4x USB-C Ports, 1x USB-A Internal Port
Ports & interfaces - Host interface - PCIe
Ports & interfaces - Expansion card standard - PCI 3.0
Ports & interfaces - Expansion card form factor - Full-height / Low-profile
Ports & interfaces - Internal USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 1
Ports & interfaces - Output interface - USB Type-C
Ports & interfaces - SATA power connector type - SATA 15-pin
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 4
Stck_Kart - 9998
System requirements - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
System requirements - Server operating systems supported - Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
System requirements - Linux operating systems supported - Yes
System requirements - Mac operating systems supported - Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma
Technical details - Compliance certificates - RoHS
ProductName - 5-Port USB PCIe Card, USB 3.2 10Gbps, PCI Express Card with 4x USB-C Ports, 1x USB-A Internal Port, USB PCIe Controller Card, Windows/macOS/Linux
HERSTELLER - STARTECH
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Storno - Y
URL - https://www.startech.com/en-us/PS4C3IA3-USB-C-CARD
