Startech 10M OM4 MULTIMODE FIBER CABLE .

ARTIKEL1 - 10M OM4 MULTIMODE FIBER CABLE
ARTIKEL2 - .
Brand - StarTech.com
BrandPartCode - 450FBLCLC10PP
Breite - 0
Category - InfiniBand & Fibre Optic Cables
Certificates - Compliance certificates - CE, RoHS
EANCode - 0065030900805
Features - Cable length - 10 m
Features - Cable type - LOMM
Features - Cladding diameter - 125 µm
Features - Connector 1 - LC
Features - Connector 1 gender - Male
Features - Connector 2 - LC
Features - Connector 2 gender - Male
Features - Core diameter - 50 µm
Features - Data transfer rate - 100 Gbit/s
Features - Fiber mode structure - Multi-mode
Features - Fibre optic type - OM4
Features - Full duplex - Yes
Features - Jacket material - Low smoke zero halogen (LSZH)
Features - Product colour - Aqua colour
Features - Wavelengths supported - 850,1300 nm
Gewicht - 0.08
GRUPPE1 - Cables
GRUPPE2 - Fiber Optic Cable
GTIN - 0065030900805
GTIN - 065030900805
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - 450FBLCLC10PP
Laenge - 0
Logistics data - Master (outer) case height - 430 mm
Logistics data - Master (outer) case length - 410 mm
Logistics data - Master (outer) case width - 410 mm
Logistics data - Products per master (outer) case - 120 pc(s)
LongDesc - Optimize fiber patch cabling in high-density patching applications where cables are prone to bendingLC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable enables 40/100G network connections. The push-pull tabs on each connector ensure quick connection and removal, facilitating accurate installation in high connection density environments. The bend-insensitive fiber and molded strain reliefs support cable runs requiring micro/macro bends while maintaining low attenuation. The retractable strain-relief housings enable toolless in-field polarity swapping. Color-coded LC-Duplex connectors ensure error-free polarity configuration.Engineered for Optimal PerformancePrecision-manufactured ceramic ferrules ensure accurate fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM4 fiber patch cable is ideal for 850nm and 1300nm Vertical-Cavity Surface-Emitting Laser (VCSEL) and LED sources.CompatibilityThis multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40G networks, ensuring a reliable connection in legacy fiber environments.LSZH Cable JacketHoused in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.Each OM4 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.The StarTech.com Advantage
LongProductName - StarTech.com 10m (32.8ft) LC (UPC) OM4 Multimode Fiber Optic Cable, 50/125, 100G, Low Insertion Loss, LSZH Fiber Jumper Cord
LongSummaryDescription - StarTech.com 10m (32.8ft) LC to LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord. Cable length: 10 m, Cable type: LOMM, Fibre optic type: OM4, Connector 1: LC, Connector 2: LC, Core diameter: 50 µm, Full duplex
Operational conditions - Operating temperature (T-T) - -20 - 60 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 200 mm
Packaging data - Package height - 20 mm
Packaging data - Package width - 230 mm
ProductName - 10m (32.8ft) LC to LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord
ShortSummaryDescription - StarTech.com 10m (32.8ft) LC to LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord, 10 m, LOMM, OM4, LC, LC
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - StarTech.com 10m (32.8ft) LC to LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord
URL - https://www.startech.com/en-us/450FBLCLC10PP
WarrantyInfo - Lifetime
Weight & dimensions - Bending radius - 6 cm
Weight & dimensions - Cable diameter - 2.9 mm
